AT2022 is a condenser mic designed for stereo recording. 2 unidirectional condenser capsules in an X/Y configuration pivot to allow for narrow (90°) or wide (120°) stereo operation
The capsules also fold flat for storage and transportation. Designed for general stereo recording and field sound capture, the AT2022 provides the spatial impact and realism of a live sound field. The microphone comes equipped with a stand clamp, AA battery, fuzzy windscreen and .5 m cable that terminates in a 3.5 mm stereo plug.
X/Y stereo microphone with unique pivoting electret condenser capsules for ultimate flexibilityProvides the spatial impact and realism of a live sound fieldBattery operation allows use with most recording devicesSwitchable low-frequency roll-off minimizes pickup of unwanted low-frequency noiseUser-selectable 90° or 120° stereo operation for narrow or wide pickup patternsIdeal for general stereo recording and field sound captureExcellent channel separationIncluded fuzzy windscreen offers excellent wind protection
ELEMENTS: Fixed-charge back plate, permanently polarized condenser
POLAR PATTERN: X/Y Stereo
FREQUENCY RESPONSE: 20-20,000 Hz
LOW FREQUENCY ROLL-OFF: 150 Hz, 6 dB/octave
OPEN CIRCUIT SENSITIVITY: -41 dB (8.9 mV) re 1V at 1 Pa
CHANNEL BALANCE: <2.5 dB
IMPEDANCE: 200 ohms
MAXIMUM INPUT SOUND LEVEL: 122 dB SPL, 1 kHz at 1% T.H.D.
DYNAMIC RANGE (typical): 103 dB, 1 kHz at Max SPL
SIGNAL-TO-NOISE RATIO: 75 dB, 1 kHz at 1 Pa
BATTERY TYPE: 1.5V AA/UM3
WARNING: The AT2022 is designed for battery operation only. Do not attempt to use when phantom power is present. Possible damage to the microphone may result.
BATTERY CURRENT / LIFE: 1.2 mA / 500 hours typical (alkaline)
SWITCH: Off, on/flat, on/roll-off
WEIGHT: 270 g (9.5 oz)
OUTPUT CONNECTOR: Integral 3-pin XLRM-type
CABLE: 0.5 m (1.6') long, 3 conductor, shielded, vinyl-jacketed stereo cable with 3-pin XLRF-type connector at microphone end and 3.5 mm (1/8") TRS connector at output end
ACCESSORIES FURNISHED: AT8405a stand clamp for 5/8"-27 threaded stands; fuzzy windscreen; battery; soft protective pouch
192.0 mm (7.56") long65.0 mm (2.56") maximum head diameter21.0 mm (0.83") body diameter
GTIN (UPC/EAN) : 4961310112448
Manufacturer Part Number : AT2022
