DPA 4188-DP-F-F34-LH
MPN #4188-DP-F-F34-LH
4188 CORE+ Directional Flex Headset Mic, 120 mm Boom, Beige, Mini-Jack
The DPA 4188 CORE+ Directional Flex Headset Microphone in beige, with a 120 mm boom and Mini-Jack connector, offers discreet, high-performance audio ideal for live speech, presentations, and theatrical applications. Its flexible, one-ear design ensures a secure and comfortable fit while blending seamlessly against light skin tones for minimal visual impact.
Equipped with CORE+ technology, this headset delivers remarkably low distortion and transparent sound across the full dynamic range. The directional cardioid capsule captures speech with precision, effectively rejecting background noise. The Mini-Jack connector provides broad compatibility with many wireless systems, making it a practical choice for professionals who require dependable, crystal-clear audio in a subtle and easy-to-wear format.
Features
Cardioid Directional Microphone: Isolates the speaker's voice while minimizing surrounding noise-ideal for speech and vocal performance.CORE+ Technology for Pristine Sound: Provides ultra-low distortion and crystal-clear audio across all volume levels.Subtle Beige Finish: Designed to be discreet and blend naturally with skin tones for low visibility on stage or camera.120 mm Boom for Flexible Placement: Allows accurate and stable mic positioning near the mouth.Mini-Jack Connector: Compatible with wireless systems using locking 3.5 mm mini-jack inputs.High SPL Handling: Performs well even with loud voices or energetic use, without distortion.Moisture Resistant: Built to resist sweat and humidity, ensuring reliable performance during active use.Comfortable and Adjustable Fit: Lightweight one-ear headset can be worn on either ear and shaped for a secure, custom fit.
Specifications
General Specifications
Model: 4188 CORE PlusType: Directional Flex Headset MicrophoneBoom Length: 120 mmColor: BeigeMounting Style: Single-ear Flex EarsetConnector: Mini-JackCapsule Type: 4088 directional capsule
Audio Performance
Directional Pattern: CardioidPrinciple of Operation: Pressure gradientCartridge Type: Pre-polarized condenserFrequency Response: 20 Hz to 20 kHzSensitivity: 6 mV/Pa, -44 dB re 1 V/PaEquivalent Noise Level A-weighted: Typically 26 dB(A), maximum 28 dB(A)Equivalent Noise Level ITU-R BS468-4: Typically 38 dB, maximum 40 dBDistortion THD less than 1 percent: 134 dB SPL RMS, 137 dB SPL peakMaximum SPL THD 10 percent: 144 dB SPL peakDynamic Range: Typically 111 dB
Electrical Characteristics
Output Impedance from MicroDot: 30 to 40 ohmsOutput Impedance with DAD6001-BC: 100 ohmsCable Drive Capability: Up to 300 meters with DAD6001-BC XLR adapterOutput Balance Principle: Signal balanced with DAD6001-BC XLR adapterCommon Mode Rejection Ratio: Greater than 60 dB from 50 Hz to 15 kHz with DAD6001-BCPower Supply via Adapter: Minimum 5 V, maximum 10 VPower Supply with DAD6001-BC: P48 phantom power, operational from 12 VCurrent Consumption: Typically 1.5 mA microphone only, 3.5 mA with DAD6001-BC
CORE Plus Technology
Distortion Elimination: Minimizes nonlinearities from membrane and electronicsAudio Fidelity: Enhanced clarity and transparency across dynamic rangeTHD Benchmark: Less than 0.5 percentCompatibility: Mixable with non-CORE Plus DPA microphones
Physical Characteristics
Microphone Boom Weight: 0.8 gramsEarhook Weight: 1.1 gramsCable Weight: 6.6 gramsTotal Weight: 8.5 gramsMicrophone Diameter: 5.4 mmCable Length: 1.3 metersCable Diameter: 1.6 mm
Environmental
Operating Temperature Range: Minus 40 to 45 degrees CelsiusRelative Humidity: Up to 90 percentElectromagnetic Compatibility: Fully compliant
Application Suitability
Ideal for speech, presentations, theater, broadcast, and live performanceLightweight, ergonomic, and discreet for comfort and visual minimalismMountable on either earCompatible with wireless systems using mini-jack connector
