Fostex 6301NX
UPC/EAN #636827304597
MPN #6301NX
$469.00
Save 19.8%, MSRP $585.00
6301-series are the standard active monitor speaker in the broadcast and production facilities and have been re-designed with the latest D-class power amplifier and new drivers.
Features
20W D-class power amplifier for higher output level and less power consumption with no heat sinkDedicated 4-inch full range driver for clear audio reproductionTraditional rugged enclosure of aluminum die-cast with the physically identical height and width to the current B-seriesFlat panel design to avoid inadvertent power-off or level changeAuto Stand-by mode (compliant to ErP directive) for energy savingDetachable IEC type power inlet with multi-voltage power handlingNewly designed mounting bracket (EB-6301) for wall mounting with variable angle adjustments
Specifications
SPEAKER SECTION
Enclosure type: closedUnit: 4" full rangeFrequency response: 70 Hz - 15k HzSound Pressure Level: 85dB / W (1m)Maximum SPL: 98dB
AMPLIFIER SECTION
Inputs
Connector: 1/4" TS Phone (unbalanced)Input Impedance: 10k ohm or moreConnector: XLR-3-31 (transformer balanced)Input Impedance: 10k ohm or more
Output (Thru)
6301ND Connector: XLR-3-32 (IEC 60958 AES/EBU)Rated utput: 20WDistortion (T.H.D.): 0.05% (1kHz / 1W output)
Residual Noise: -70dBV or less
Input Sensitivity:
1/4" TS phone: -14dBV (0.2Vr.m.s.)XLR: +4dBu (1.2Vr.m.s.)Auto Stand-by: active after approx. 25 min. of continuous input lower than the threshold level
GENERAL
Dimensions: 120 (W) x 189 (H) x 120 (D) mmWeight: NX 2.3kgsPower Requirement: AC 100 - 240V (50/60Hz)Power Consumption: 10W (less than 0.5W in stand-by mode)
