RME M16DA

UPC/EAN #4260123362591 MPN #M16DA

$5781.00

Financing available

Be the first to write a review

Free shipping in Canada. Conditions

16 channel MADI/ADAT to analog converter

Combinations of the M-16 DA and M-32 DA converters allow for setups with 16, 32, 48, or 64 channels, according to your individual application or budget. The unit's unique set of features includes three hardware reference levels up to +24 dBu, MADI I/O and ADAT input up to 192 kHz, 6.3mm TRS and D-sub outputs, remote control via MIDI, and operation across a wide range of mains voltages, all packed into a 2U enclosure.

The M-16 DA extends RME's MADI line with multichannel conversion in reference quality - at an unbeatable price/performance ratio!

Features

16-channel DA converter, double balanced output, 118 dBA

19" enclosure with only 2 units height

1 x MADI I/O, 32 channels @ 96 kHz, 16 channels @ 192 kHz

4 x ADAT In, 16 channels @ 96 kHz, 8 channels @ 192 kHz

Automatic Delay Compensation: no user operation necessary when stacking units

16 LED level meters with 6 LEDs each

SteadyClock(TM) - pristine sound quality independently from the quality of the external clock signal

SyncCheck(TM) - unique technology to check clock synchronization

Noise suppression on power-on and power-off at the analog outputs

All settings are stored permanently

Fully remote controllable via MIDI and MIDI over MADI

No fan

Lower power consumption, 40 Watts

Specifications

Input DA: 4 x ADAT optical, 1 x MADI optical/coaxial

Output DA: 1/4" TRS jack servo balanced, up to +21 dBu. 25 pin D-sub, balanced, up to +24 dBu

Dynamic Range DA (SNR): 114 dB RMS unweighted, 118 dBA

THD DA: < -104 dB (< 0.00063%)

THD+N DA: < -100 dB (< 0.001%)

Crosstalk DA: > 110 dB

Frequency response DA, -0.5 dB: 5 Hz - 22 kHz (sf 48 kHz)

Frequency response DA, -0.5 dB: < 5 Hz - 34 kHz (sf 96 kHz)

Frequency response DA, -1 dB: < 5 Hz - 50 kHz (sf 192 kHz)

Input level for 0 dBFS: +24 dBu, +19 dBu, +13 dBu

Sample rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz, variable (Sync/WC)

Jitter: Typical < 1 ns for internal, Word Clock, ADAT and MADI input

Jitter suppression: >30 dB (2.4 kHz)

Jitter sensitivity: all PLLs operate error-free even at 100 ns

Power supply: Internal switching mode PS, 100V - 240V AC, 60 Watt

Dimensions: (WxHxD) 483 x 88 x 200 mm
