Aputure LS 600d (V-mount)
UPC/EAN #6971842183630
MPN #APA0212GW3
600W daylight-balanced point-source LED with 8 preset special effects, active cooling, Onboard, wireless, DMX & app control and includes reflector, clamp & rolling bag
MORE POWER FOR MORE PEOPLE
When we released the LS 600d Pro, we also made a promise to create a tool that was more accessible and would revolutionize the amount of output most creatives had access to. The Light Storm 600d is a perfect light for any demanding lighting situation you may encounter as a cinematographer or photographer.
RAISING THE STANDARD
Utilizing the same light source as its professional predecessor, its immensely powerful 600W COB LED positions the LS 600d as one of the brightest point source LEDs on the market. It outputs an incredible 8,500+ lux with the Hyper-Reflector or up to 29,300+ lux at 3 meters with the F10 Fresnel.
UNIVERSAL BOWENS MOUNT
As a member of the Light Storm family, the LS 600d also features an integrated Bowens Mount for easily attaching accessories and modifiers, ranging from the F10 Fresnel for intense brightness to the Light Dome 150 for spectacular softness.
SLIMMER CONTROL BOX
The LS 600d's control box is significantly lighter than the LS 600d Pro's controller. The LS 600d control box weighs in at 3.24kg (7.14lbs), which is almost half the weight of the LS 600d Pro's 5.8kg (12.79lbs) control box. While shedding nearly half of its weight, the LS 600d controller still maintains many of the LS 600d Pro's control methods and functions, like 2.4G Remote Compatibility, DMX512 In & Out, & Sidus Link.
SIDUS LINK APP
For photographers and video creators who require convenient access to intense output with the support of the Aputure and Sidus Link ecosystems, the LS 600d is an excellent tool. Integrating the LS 600d into onset workflows with Sidus Link and DMX512 control gives creators a powerful fixture that seamlessly integrates into their existing ecosystems with smooth dimming control and without color shift or the need to use scrims to decrease output.
CURVED YOKE
As it uses the same structure as the LS 600d Pro lamp head, the lamp head of the LS 600d maintains the curved yoke from its older brother. This curved yoke that is missing on comparable light fixtures grants the LS 600d increased tilt range when used with larger light modifiers, such as the F10 Fresnel, Light Dome 150, or Light OctaDome 120.
0-100% DIMMING
Like LS 300d II and 300x, the LS 600d can dim as low as 0% in 1% increments, providing filmmakers and photographers with immensely more control than traditional fixtures and strobes.
SAFE & EASY TRANSPORTATION
The LS 600d comes ready to go for any situation, with its padded rolling case.
Features
Output: 98,500 Lux at 3.3' w/ Reflector5600K CCTAC or Battery PowerOnboard, Wireless, DMX & App ControlCRI 96 | TLCI 96 | CQS 94 | SSI 72Active CoolingBowens S Accessory Mount8 Preset Special EffectsIncludes Reflector, Clamp & Rolling Bag
Specifications
CCT: 5600K±200KCRI: ?96TLCI: ?96CQS: ?94SSI (D56): ?72TM-30 RF (Average): 92TM-30 RG (Average): 102Beam Angle (No Accessories): 105°Beam Angle (LS 600 Series Hyper Reflector): 55°Beam Angle (F10 Fresnel): 15° ~ 45°Lumens: 62,187lmMax Power Output: ?600WMax Power Consumption: ?720WMax Operating Current: 8A MaxOperating Voltage (Power Supply): 100V~240V, 50Hz/60HzOperating Voltage (Battery): V-Mount / Gold Mount (Two Batteries) | Half Output: 12.5V-16.8V (14.4/15A) 22V-33.6V (26V/8.5A, 28.8V/7.5A)Operating Voltage (Battery): 3-Pin XLR (48V DC) | Full Output: 48V/15ADC Input: 1x 48V 3-Pin XLR DC Input (720W)Operating Temperature: -20°C ~ 45°C / -4°F ~ 113°FDimming: 0-100%; Linear, Exponential, Logarithmic, S-CurveControl Methods: On-board, 2.4GHz, Sidus Link (Sidus Mesh?), 5-Pin XLR DMX512 In & OutWireless Operating Range (Bluetooth): ?80mWireless Operating Range (2.4GHz): ?100mScreen Type: OLEDFirmware Upgradeable: USB (FAT16/FAT32), Sidus LinkCooling Method: Active CoolingCable Type (Head Cable): LS 600 Series 5-Pin Weatherproof Head Cable (3m)Cable Type (Max Head Cable Length): 7.5mCable Type (Power Cable): Neutrik powerCON TRUE1 TOP AC Cable (6m)Construction Material: Magnesium AlloyAccessory Mount: Bowens MountTilt Angle: 360°Mounting: 16mm / 28mm | 5/8in (Baby Pin) / 1.125in (Junior Pin)Carrying Case: Telescoping Handle, WheelsEstimated LED Lifetime (L70): 50,000HEst. Color Shift Over Lifetime (CCT): 2% (6,000H)Est. Max Flicker-Free FPS: 2,000 FPSCertifications: CE, FCC, ROHS, KC, NCC, PSE, BIS
Photometrics
105° at 5600K: 2057 fc / 22,150 Lux at 3.3' / 1 m, 241 fc / 2600 Lux at 9.8' / 3 m, 94 fc / 1020 Lux at 16.4' / 5 m55° at 5600K: 9150 fc / 98,500 Lux at 3.3' / 1 m (with Reflector), 789 fc / 8500 Lux at 9.8' / 3 m (with Reflector), 278 fc / 3000 Lux at 16.4' / 5 m (with Reflector)
DIMENSIONS
Lamp Head w/o Yoke: 30.8 x 15.61 x 15.01cm / 12.13 x 6.15 x 5.91inLamp Head w/ Yoke: 30.8 x 25.03 x 45.6cm / 12.13 x 9.85 x 17.95 inControl Box (V-Mount): 28.2 x 15.4 x 9cm / 11.1 x 6.1 x 3.54inControl Box (Gold Mount): 28.2 x 15.4 x 9cm / 11.1 x 6.1 x 3.54inLightning Clamp: 10.35 x 8.74 x 12.5cm/ 4.07 x 3.44 x 4.92inRolling Case: 60.7 x 40 x 37.2cm / 23.9 x 15.75 x 14.65in
WEIGHT
Lamp Head w/ Yoke: 4.69kg / 10.34lbsControl Box (V-Mount): 3.24kg / 7.14lbsControl Box (Gold Mount): 3.24kg / 7.14lbsLightning Clamp: 670g / 1.48lbsTotal w/ Case: 16.71kg / 36.84lbs
