The latest addition to the Neve outboard range, the 1073DPA provides two of the world famous Class A Neve 1073 microphone pre-amplifiers. This classic design is the consummate mic pre for recording vocals, guitars and acoustic instruments of all descriptions. The sought after Neve Sound is now available in a cost effective 1U box.
Mic Input
1200ohm (Hi-Z) or 300ohm (Lo-Z) input impedance transformer coupled stage. 48V is switchable onto the Mic Input. Mic gain is across two class A gain stages. The signal then feeds a transformer balanced class A output stage via a +/-10dB trim.
Line Input
20k input impedance, +26dBu peak signal level. Electronically balanced input stage. Either a 1/4inch jack or a male XLR can be used. Gain from this input is
applied in the second class A gain stage and is output through the same class A transformer coupled output stage as the Mic In.
Line Output
Phase reversal is available pre Line Output. The Line Output has a minimum +26dBu peak output level. The peak LEDs will illuminate 3dB below clipping.
Specifications
Input Impedance
Mic switchable Line : 300ohm or 1200ohm, 20kohm
Frequency Response
60dB gain into 600ohm +/-0.5dB : 20Hz to 20kHz
60dB gain into 600ohm -3dB : 20Hz to 40kHz
