BLACKMAGIC DESIGN

Micro Converter BiDirect SDI/HDMI 3G

Format Converters

Ultra-compact bidirectional converter, SDI↔HDMI, supports SD/HD up to 1080p60, USB-C powered, broadcast-grade design, reclocking, metal enclosure, 3G-SDI.

$105.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The Blackmagic Micro Converter BiDirectional SDI/HDMI is an ultra-compact, USB-powered video converter designed to bridge the gap between professional SDI gear and consumer HDMI devices. Unlike typical one-way converters, this bidirectional model simultaneously converts SDI to HDMI and HDMI to SDI, even in different formats. It’s perfect for pairing consumer cameras with pro switchers or extending HDMI runs via SDI without adding bulk to your setup.

Engineered to broadcast standards, this converter supports a wide range of SD, HD, and 3G-SDI video formats up to 1080p60, and it features reclocking for clean signal transmission. The all-metal housing ensures durability in demanding production environments, while the USB-C port powers the unit and allows access to settings via Mac or Windows. A power supply with international adapters is included.

Features

Dual Conversion in One Device
Simultaneously converts SDI to HDMI and HDMI to SDI even in different formats.

Ultra-Compact, Broadcast-Grade Design
Pocket-sized metal enclosure built for professional use in live production, broadcast, and on-set workflows.

USB Powered for Maximum Flexibility
Runs via USB-C from TVs, laptops, or other USB power sources. No bulky power bricks required.

Supports Multiple Formats
Compatible with SD, HD, and select 2K video formats; automatic format detection and switching.

High-Quality Signal Processing
Includes SDI reclocking for stable, low-jitter signal transmission.

Camera Control Protocol Support
Allows use of Blackmagic Pocket Cinema Cameras with SDI live production switchers.

Rugged All-Metal Construction
Built for durability in demanding environments, with reliable professional-grade connectors.

Multiple Standards and Resolutions Supported
Works with 525i/625i, 720p, 1080i, 1080p, and 2K DCI video formats with 4:2:2 YUV color.

USB Utility Control
Configure settings and update firmware using the Blackmagic Converter Utility on Mac or Windows.

Power Supply Included
Option to purchase with universal AC power supply (with 4 international adapters) or without.

Specifications

General Specifications
Product: Blackmagic Micro Converter – Bidirectional SDI ⇄ HDMI
Type: Miniaturized broadcast video converter
Enclosure: All-metal, ultra-compact design
Power: USB Type-C (powered via computer, TV, or AC adapter)
Software Utility: Mac and Windows compatible via USB-C
Included: Optional AC power supply with international plug adapters (model dependent)

Conversion Capabilities
Function: Simultaneous SDI to HDMI and HDMI to SDI conversion
Supported Formats: SD and HD
Reclocking: Yes (ensures signal integrity)
Camera Control: Supports protocol conversion for Blackmagic Pocket Cinema Cameras to SDI switchers

Inputs & Outputs
SDI Video Input: 1 × SD, HD, or 3G-SDI
SDI Video Output: Automatically matches HDMI video input
HDMI Input: HDMI Type A
HDMI Output: HDMI Type A
USB Type-C: Power, configuration, and firmware updates

Standards Support
SDI Video Standards
525i59.94 NTSC
625i50 PAL
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
1080PsF25, 1080PsF29.97, 1080PsF30
1080i50, 1080i59.94, 1080i60
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI, 2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI
2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI

HDMI Video Standards
525i29.97 NTSC
625i25 PAL
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60

Color Specifications
SDI Color Precision: 4:2:2
SDI Color Space: YUV
HDMI Color Precision: 4:2:2
HDMI Color Space: YUV

Compliance & Standards
SDI Compliance: SMPTE 259M, 292M, 296M, 424M, 425M
SDI Video Rates: Auto-switching between SD and HD; Level A or B selectable via setup utility
SDI Auto Switching: Automatically detects SD, HD, 3G-SDI

Use Case & Applications
Portable solution for HDMI ⇄ SDI conversion
Ideal for live production, broadcast, AV installations, and on-set monitoring
Extends HDMI over long distances using SDI
Enables integration of HDMI consumer gear with SDI professional workflows
