QU-7D

Dante Built-In: Includes a 16-16 Dante interface (48/96 kHz) with a locking EtherCon port for seamless integration into networked audio systems.

33 Motorised Faders: Full hands-on control with four customizable layers and instant recall via motorised faders.

32 Mic/Line Inputs: Plenty of onboard inputs via combi XLR/jack sockets to handle large sessions or live shows.

20 XLR Outputs: Generous number of balanced outputs to feed speakers, monitors, and zones.

96kHz XCVI Core: Pristine high-resolution audio processing powered by Allen & Heath's trusted FPGA engine.

Enhanced Workflow: Features updated touchscreen, per-channel displays, and flexible patching for a faster, smarter mix experience.

Comprehensive Recording: Multitrack via USB-C (32-32), SD card (up to 32-32 @ 48kHz), and stereo USB-A record/playback.

DEEP Processing & FX: Supports advanced DEEP processing plugins and includes 6 onboard FX engines with stereo returns.

Smart Mixing Tools: Gain Assistant and Feedback Assistant simplify setup and help avoid technical issues during shows.

Automatic Mic Mixer: Integrated 32-channel AMM for clean speech mixing in live, conference, and broadcast environments.

Flexible Expansion: Equipped with a 128-128 SLink port to connect to remote I/O, stageboxes, or other mixers.

Remote Control Ready: Mix wirelessly via free apps on iOS, Android, macOS, or Windows.

General Specifications

model: Qu 7D

96kHz XCVI FPGA core digital mixer with integrated Dante

DEEP processing ready

total input channels to mix: 38

32 mono (linkable)

3 stereo

total output buses: 24

redesigned 7 inch capacitive touchscreen

33 motorised 100mm faders

4 fully customisable fader layers

8 assignable SoftKeys

dual footswitch input (single or dual switch compatible)

per-channel OLED display and chromatic LED metering

Audio Performance

updated high-resolution mic preamps

96kHz AD/DA converters for pristine signal integrity

low-latency signal path

Input and Output I/O

32 XLR/TRS combi mic/line inputs

2 stereo line input pairs (each 2x TRS)

20 XLR outputs

2 TRS outputs

1 AES3 stereo digital output (XLR)

1 talkback input (XLR)

stereo headphone output

12V lamp socket

Mix Architecture

12 mix outputs

6 mono or linkable aux/group

6 stereo aux/group

4 mono or linkable matrix outputs

stereo main LR output

6 multi FX engines with dedicated stereo returns

Dante Networking

integrated 16x16 Dante interface

supports 48kHz and 96kHz operation

locking EtherCon port for stable Dante connectivity

ideal for integration in large AV systems, installations, or broadcast

Digital Expansion

128x128 SLink intelligent port for I/O expansion and stageboxes

flexible input/output patching across all interfaces

Recording and Playback

32x32 USB-C audio interface for multitrack recording/playback

USB-A port for stereo record/playback and data transfer

SD card slot for multitrack audio

16x16 at 96kHz

32x32 at 48kHz

Assistive DSP Features

Gain Assistant for automated gain staging and level monitoring

Feedback Assistant with up to 16 adaptive filters per output

32 channel Automatic Mic Mixer (AMM) with real-time DSP and zero latency

Remote Control Support

control via free apps for Windows, macOS, iOS, Android

full access to mix, routing, FX, and system setup remotely

Chassis and Build

rugged desktop chassis with optional 19 inch rackmount kit

streamlined control surface for fast access in live, studio, or fixed install settings
