LECTROSONICS

DBu Bodypack Transmitter LEMO

Bodypack Transmitters Accessories

Digital UHF bodypack transmitter (470–608 MHz), 3-pin LEMO input, 25/50mW RF power, AES 256-bit encryption, 5-hour runtime on 2 AA batteries, OLED display, SMA antenna, DSP limiter, servo-bias input, IR sync, rugged aluminum housing

$2,800.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The Lectrosonics DBu-LEMO Digital Bodypack Wireless Transmitter (470 to 608 MHz) is a powerful, professional-grade transmitter designed for seamless integration into Lectrosonics’ D-Squared digital wireless systems. Compact, rugged, and feature-rich, the DBu-LEMO is purpose-built for broadcast, theater, film, and live production environments that demand high audio quality, security, and reliability. Its wideband UHF tuning range (470.1 to 607.95 MHz) offers flexibility in crowded RF environments, while AES 256-CTR encryption with three security modes (Standard, Shared, Universal) ensures signal confidentiality for sensitive applications.

Designed around a 3-pin LEMO input with servo bias, the DBu accommodates a variety of lavaliers, headset mics, dynamic microphones, and even line-level signals. Its DSP-controlled input limiter, high-quality preamp, and 44 dB of gain adjustment in 1 dB steps provide clean, studio-grade audio performance. Users can choose between 25 and 50 mW RF output power, balancing range and battery life. Housed in solid machined aluminum with a durable black electroless nickel finish, it features a detachable antenna, backlit LCD, and a programmable top-panel switch that can serve as a mute, talkback, or power button.

The DBu offers up to 5 hours of operation on two AA batteries and includes a secure battery door and belt clip designed to withstand daily field use. IR sync enables quick pairing with compatible receivers, while firmware updates can be performed via the side-mounted USB port. Though it lacks built-in mobile app compatibility, the optional LectroRM app (sold separately) provides remote control over key settings like frequency and input level via encoded audio signals. With its reliable build, intelligent signal processing, and streamlined control interface, the DBu-LEMO is a trusted solution for professionals who need compact digital wireless performance with uncompromising audio quality.

Features

Digital Bodypack Wireless Transmitter (470–608 MHz)
Designed for use with Lectrosonics D-Squared digital systems, delivering secure, studio-quality wireless performance.

Wide Compatibility with Mic and Line Sources
3-pin LEMO connector with servo-bias circuitry supports lavaliers, headsets, dynamic mics, and line-level inputs.

Selectable RF Power Levels
Choose between 25 or 50mW for optimal range and battery life in various environments.

AES 256-Bit Encryption
Three key modes (Standard, Shared, Universal) ensure secure transmission for professional and high-security applications.

High-Performance Preamp and Limiter
Offers a 44 dB gain range with a DSP-controlled analog limiter to prevent overload and distortion.

Durable All-Metal Construction
Machined aluminum housing with rugged ebENi finish, built to withstand field use.

Simple Setup and Operation
Backlit LCD, membrane buttons, and IR sync for easy menu navigation and fast receiver pairing.

Programmable Function Switch
Top-panel switch can be set for mute, power, or talkback; customizable for your workflow.

Battery Powered and Efficient
Operates for up to 5 hours on two AA batteries; battery door is secure and impact-resistant.

Remote Control Ready with LectroRM App
Supports wireless remote adjustments via encoded audio tones from iOS or Android devices (app sold separately).

Specifications

General Specifications
Device Type: Digital Bodypack Wireless Transmitter
Frequency Range: 470.1 to 607.95 MHz
Wireless Technology: Digital UHF
Compatibility: D-Squared Digital Systems
Encryption: AES 256-bit CTR (Standard, Shared, Universal)
Construction: Machined aluminum with black electroless nickel finish
Display: Backlit LCD
Control Interface: Membrane switches, IR Sync, LectroRM App
Firmware Updates: USB Micro-B (via side panel)
Max Operating Range: 300 ft / 91.4 m

Audio Specifications
Input Connector: LEMO 3-pin male
Input Types: Microphone, Line-level, Dynamic
Bias Power: 5 V Plug-in Power, 0–4 V Servo Bias
Gain Range: 44 dB (adjustable in 1 dB steps)
Limiter: DSP-controlled analog limiter, >30 dB range, dual-release envelope
Auto Gain: Yes
Mute: Programmable Mute or Talkback Switch
Sync Method: IR

RF Specifications
RF Output Power: 25 / 50 mW
Antenna: Removable flexible whip, SMA connector

Power Specifications
Battery Type: 2x AA (included)
Battery Life: Up to 5 hours (alkaline)

Physical Specifications
Dimensions: 3.4 x 2.4 x 0.7 in / 86 x 62 x 19 mm
Weight: 6.2 oz / 177 g (with batteries)
Belt Clip: Stainless steel spring-wire (removable)
Environmental Resistance: Not rated for water or dust resistance
