RME

HDSPe AES

PCI/PCIe

24bit / 192kHz, PCI Express card, 32 channel AES/EBU

$1,745.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The card is also equipped with two MIDI I/O ports, word clock I/O, and can be used with the optional TCO module for synchronization to LTC and video.

The HDSPe AES is RMEs reaction to requests from audio professionals for an AES-based solution with the typical RME features and quality. This audio card is a perfect all-in-one solution for professional users in the fields of broadcast, TV, theater, stage/PA - and in any professional studio.

The card's mainboard contains word clock I/O and a 25-pin D-sub connector, providing four AES inputs and four AES outputs via standard digital breakout cable (Tascam pinout). The sensitive word clock input operates on Single, Double and Quad Speed signals automatically. The expansion board adds audio channels 9-16 and a connector for a MIDI breakout Cable with two MIDI I/Os (four 5-pin DIN connectors). It does not require a PCIe slot.

The card is not based on a PCI to PCI Express bridge, which would simply add PCIe to existing PCI technology. It is a newly developed genuine PCI Express solution, which consequently takes full advantage of the new format, achieving significant performance gains in multitrack audio and lowest latency.

A PCI Version (HDSP AES-32) is available.

Connectivity:

  • PCI Express interface
  • 16 input channels / 16 output channels
  • 8 x AES/EBU I/O
  • 2 x MIDI I/O
  • Word Clock I/O
  • TotalMix
  • optional: HDSP TCO
    •

    Features

    Support for 192 kHz at full channel count

    Native support for Double and Quad Wire transfer

    Direct conversion between these formats

    SteadyClock for highest jitter suppression and clock regeneration

    Intuitive and clearly laid-out user interface

    TotalMix: 512 channel mixer with 42 bit internal resolution

    48 level meter Peak/RMS, hardware-computed

    Specifications

    All settings: changeable in real-time

    Automatic and intelligent master/slave clock control

    Enhanced Zero Latency Monitoring for latency-free submixes and perfect ASIO Direct Monitoring

    Sync sources: 8 x AES, word clock, internal

    Varipitch: by input signal or word clock

    Sample rates: 32 kHz up to 192 kHz, variable (Sync/word clock)

    Sample rate range: AES: 28 kHz - 204 kHz, word clock: 28 kHz - 204 kHz

    Jitter: < 1 ns, internal and all inputs

    Jitter sensitivity: PLL operates even at 100 ns Jitter without problems

    Comes with DIGICheck: the ultimate measurement, analysis and test tool

    Input 8 x AES, 2 x MIDI, word clock (BNC)

    Output 8 x AES, 2 x MIDI, word clock (BNC)

    Input word clock: BNC, Signal Adaptation Circuit (functional from 1.2 Vpp input signal), termination via jumper

    Output word clock: BNC, low-impedance driver stage, 4 Vpp into 75 Ohms, short-circuit-proof

    MIDI input and output: via four 5-pin DIN jacks
