TEGELER AUDIO  |  SKU: 19448

MythEQ 500

Active 500 series equalizer module


$895.00 CAD
Shipping calculated at checkout.

Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

How to come up with a new equalizer without replacing the previous one That was the main question on our minds. The Classic Equalizer EQP-1 scores with its nice warm sound. So it was clear: we needed to create a Yang to our Yin EQ. A device that works in a cleaner way, but is also capable of biting " and still retaining the Tegeler character. A device that you can use to get a warm and melodious sound, as well as drastic and aggressive EQ settings.

One device to EQ them all... ... to distort them, tweak to weak them, boost or attenuate them, surgically cut frequencies or create beautiful new peaks and valleys. Our new EQ now brings all these features together.

Why MythEQ Because after "Legendary" comes "Mythical" Naming the newest member of the Tegeler family through a Facebook poll was an exciting experiment for us - and you guys did not disappoint. We were honored by the rationale for the new name, thank you:

"After a legendary device, only a mythical one can follow from you"

Born was the MythEQ.

Sit back, relax, and go on a ride with your new EQ Your vocal track still lacks some sunshine No problem: turn the high pass filter up to 10kHz and boost it until the vocals shine as bright as the sun itself.

Your kick is missing the thump Take the bandpass filter, set it to 80Hz and boost until the neighbor knocks.

Your snare isn't loud enough for deaf 2kHz hip-hoppers Take the bandpass filter, set it to the right frequency, and boost until everyone in the back row can hear again.

The bassline isn't pushing enough for the Techno junkie Take the low-pass filter, set it to 300Hz and push until he feels the bass in his stomach.

Just a few knob twists away from great sound. With its incredibly wide operating range of -15 to +15dB, you can bring out any sound, no matter how quiet, or give the too loud ones the appropriate damper. The Q faktor of the boost and czt is proportional to the gain/attenuation. The more you boost/Attenuate, the narrower the bell.

The icing on the (MythE)Q

  • To round off the sound and add a little more Tegeler character, we eventually decided to install our in-house transformers.
  • We have made countless listening tests and decided on the most beautiful sound.
  • Transformers provide a pleasant compression of the sound through the conversion current->magnetic field->current and their non-linearities.
  • The bass becomes tidier and more defined. The heights are pleasantly rounded.
  • Get mythical! Test the EQ in your setup. Imagine how it will nestle perfectly in your setup and lift your sound to the next level. The hours of tedious "looking for the right EQ plugin" are finally over.

    Because you now have the EQ to EQ them all.

    Features

    API-500 series mono equalizer

    Toggle switch: in/bypass

    High band shelf filters: 3kHz, 3.3kHz, 3.7kHz, 5.5kHz, 8.5kHz, 10kHz

    Upper midrange bell filter: 1kHz, 1.5kHz, 2.5kHz, 4.5kHz, 12kHz, 16kHz

    Lower midrange bell filter: 80Hz, 120Hz, 190Hz, 330Hz, 900Hz, 1.3kHz

    Low band shelf filter: 50Hz, 55Hz, 65Hz, 100Hz, 300Hz, 450Hz

    Maximum boost/cut: +-15dB

    Specifications

    Frequency response: 20Hz-40kHz

    Maximum input level: +20dBu

    Input impedance: ≥2.4kΩ

    Output impedance: <600Ω

    Maximum output level: +21dBu

    Dynamic range: ≥100dB

    Supply voltage: +-16V

    Fuse: -

    Maximum current consumption: 80mA

    Size: standard API 500 module size

    Weight: 540g
