ANTELOPE AUDIO  |  SKU: 10915

Pure2

2 ch. Converters

The Pure2 is a high-end Mastering AD/DA Converter, powered by Antelope Audio's legendary clocking and pristine analog circuitry

$3,660.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

Pure2 is a mastering-grade 24-bit, 192 kHz AD/DA 2-channel converter and master clock that includes a relay-controlled volume attenuator. It features Antelope Audio's world-renowned Acoustically Focused Clocking (AFC) technology, and also utilizes pristine analog circuitry, driven by a proprietary multi-stage linear power supply for unsurpassed digital clarity and analog realism.

LEXIBLE CONTROL Access all Pure2 features via Mac & PC app or through the front-panel controls All Pure2 features are available in an intuitive software control panel for Mac or Windows provides users the ability to manage all facets of the device operation. Pure2 is also configurable via the front panel with user-definable presets.

EASY LIFE We know the engineer's life Fis not a glamorous one. So we tried to make it easier. You can set up Pure2 in a couple of minutes. All you actually need is one USB cable (provided in the box) and a laptop of your choosing (Win 7.1 or higher / Mac OSx 10.9 or higher) and you can start capturing stereo audio at 192 kHz. After setting it up, just download the Control Panel, a few clicks and you're set.

Features

A/D converter with optimized overload handling

D/A converter with dual-DAC architecture

High-end headphone amp with dedicated D/A converter

Relay-based analog volume control for accurate monitoring

Master clock with 4th-generation Antelope AFC jitter management

Connections for S/PDIF, TOSlink, AES, and USB

Intuitive software control panel for Mac/Windows

Specifications

Inputs

1x World Clock

1x 10 MHz Atomic Reference

1x SPDIF

1x TOSLINK

1x AES

USB 2.0 on Type B

1x Analog (ADC) on Combo XLR

* Factory preset to accept 22dBu, trim to accept 8dBu to 24dBu

Outputs

1x USB 2.0 on Type B

1x AES

1x SPDIF

1x TOSLINK

8 x World Clock

1x Main Analog (DAC 1) on XLR

1x Monitor Analog (DAC 2) on 1/4" TRS

1x Headphones(DAC 3)on 1/4" TRS

Operating Temperature

0-45ºC/32-113ºF

Weight (approx. prior)

~3kg/ 6,5lb approx.

Dimensions (approx.)

Width: 482 mm/19" /Rack/

Height: 44 mm/1U/

Depth: 350 mm

Power Supply

Nominal 100-120 / 220-240 VAC, 50 or 60 Hz

Actual 95-264 VAC, 50 or 60 Hz

SYSTEM REQUIREMENTS

Windows

OS: Windows 7/8/8.1/10

Disk Space: Minimum 512 MB available disk space

USB: 1x USB 2.0 Port

Required USB bandwidth: 80%-90%

CPU: Intel or AMD equivalent CPU with at least 2GHz operating frequency

Memory (RAM): 4GB Minimum (8GB or more Recommended)

MAC

OS X: 10.9/10.10/10.11/10.12 (Sierra Recommended)

Disk Space: Minimum 512 MB available disk space

USB: 1x USB 2.0/3.0 Port

Required USB bandwidth: 80%-90%

Memory(RAM): 4GB Minimum (8GB or more recommended)

CPU: Intel Core 2 Duo (Minimum) Intel Core i3 ™ or higher (Recommended)

Additional Info: Internet connection required for product activation.
