Symphony I/O MKII Chassis with Thunderbolt/ProTools HD+/Dant

Includes Symphony Mk II chassis with all three connectivity options: Thunderbolt, Pro Tools HD Plus, and Dante.

Offers maximum flexibility for hybrid studios and networked audio setups.

Compatible with Mac and PC for use with a wide range of DAWs and workflows.

Ready to accept any Apogee I/O modules (sold separately), supporting up to 32 analog channels.

Intuitive touchscreen interface for fast and easy control of routing and monitoring.

Enables immersive audio workflows, supporting formats like Dolby Atmos and Sony 360.

Delivers premium-quality AD/DA conversion and ultra-low latency.

Built in the USA for reliable, professional-grade performance.

General Specifications:

Product: Apogee Symphony Mk II

Model: Symphony I O MKII chassis with Thunderbolt, Pro Tools HD Plus, and Dante Plus cards

Configuration: Chassis only with integrated Thunderbolt, Pro Tools HD Plus, and Dante Plus connectivity cards; no I O modules included

Display: Intuitive touchscreen interface

Modularity: Supports up to 32 channels of analog I O via user-selected modular cards

Power: 90 to 240 VAC, 50 to 60 Hz, 150 W

Build: Designed and built in the USA

Connectivity Options:

Platform: Thunderbolt, Pro Tools HD Plus, Dante Plus

Thunderbolt Compatibility: Mac OS 10.10 and above

Pro Tools HD HDX Compatibility: Mac or PC with Pro Tools HD 9 or greater

Dante Compatibility: PC compatible

Digital Conversion Specifications (available with I O modules):

Analog to Digital THD plus N: minus 115 dB at 22 dBu unweighted

AD Dynamic Range: 122 dB A weighted

Digital to Analog THD plus N: minus 119 dB at 21 dBu unweighted

DA Dynamic Range: 126 dB A weighted

Frequency Response: 44.1 kHz to 20 kHz plus minus 0.05 dB

Headphone Output:

Connector: 1 stereo quarter inch front panel

THD plus N: minus 110 dB at 19 dBu into 600 Ohm, minus 101 dB at 14 dBu into 32 Ohm

Dynamic Range: 121 dB A weighted

Output Design: Apogee Constant Current Drive

Monitor Control and Immersive Audio:

Thunderbolt Monitor Workflows: Supports up to 32 speaker outputs

Immersive Audio Ready: Compatible with Dolby Atmos and Sony 360 Reality Audio

Use Case:

Ideal for professional studios needing maximum flexibility and redundancy with Thunderbolt, Pro Tools HD, and Dante platforms

Requires additional modular I O cards for input and output functionality

SKU and Configuration:

SKU 1: Symphony I O MKII chassis

SKU 2: Thunderbolt, Pro Tools HD Plus, and Dante Plus interface cards installed

Configuration Type: Chassis with full connectivity, no analog or digital I O modules installed
