RODE

RODECaster Video

Switchers

Six video inputs, HDMI I/O, dual USB-C, NDI support, APHEX audio, wireless mic receivers, chroma key, touch controls, live streaming, ISO recording.

$1,449.00 CAD $1,689.00
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The RØDECaster Video is a professional video and audio production console built for content creators who need an efficient, all-in-one solution. It combines multi-camera video switching with a high-quality audio mixer, offering a streamlined workflow for studio production, video podcasts, interviews, and live streaming. With intuitive controls and integrated hardware, it reduces the need for multiple devices and complex setups, allowing users to focus more on creating and less on configuration.

It supports up to six video inputs, including four HDMI and two USB-C connections for cameras or compatible devices. Users can build and trigger up to seven fully customizable scenes using layered video, graphics, and media elements. The console features integrated wireless receivers for RØDE microphones, APHEX audio processing across nine audio channels, and automatic background replacement with built-in chroma keying. Content can be streamed over Wi-Fi or Ethernet and recorded directly to external USB storage, with options for multitrack audio and isolated video files for flexible post-production. All settings, routing, and scene controls are accessible via the touchscreen or through the companion RØDECaster App for remote operation.

Features

All-in-One Video & Audio Console
Combines video switching, recording, and professional audio mixing in a single device.

Multiple Video Inputs
Supports up to six video sources including four HDMI and two USB-C inputs.

Scene Switching Made Easy
Switch between seven customizable video scenes with a single button press.

Broadcast-Quality Audio
Delivers clean, professional sound using low-noise Revolution Preamps™ and APHEX® audio processing.

Built-In Wireless Mic Support
Includes dual receivers for direct connection to RØDE wireless microphones.

Flexible Connectivity
Connects to cameras, computers, USB microphones, and other RØDE devices through HDMI and USB-C.

Touchscreen Control
Features a 2-inch high-resolution display and rotary dial for fast navigation and settings adjustment.

Visual Layering and Media Tools
Create scenes with video layers, media clips, and graphics, including support for green screen (chroma key).

Smart Auto-Switching
Automatically changes video sources or scenes based on audio input detection.

Stream and Record Simultaneously
Stream directly to platforms like YouTube, Facebook, or Twitch while recording to USB storage.

NDI® and Network Camera Support
Compatible with network cameras and PTZ control via Ethernet, plus mobile streaming with the RØDE Capture app.

Compact and Portable
Designed for desktop use with a streamlined footprint, ideal for studios, podcasts, or live events.

Remote Control via App
Adjust audio, switch scenes, and configure settings remotely using the RØDECaster App.

Specifications

General Specifications
Device Type: All-in-One Video and Audio Production Console
Processor: High-Performance Octa-Core CPU
Touchscreen: 2-inch High-Resolution Display
Rotary Encoder: Multifunctional, Front Panel
Weight: 1257 g
Dimensions: 305.9 mm (W) x 132.5 mm (L) x 61.4 mm (H)
Construction: Designed and Made in Australia
Power Requirements: USB-C PD 60W, 20V 3A

Video Input/Output
Total Video Inputs: 6
HDMI Inputs: 4 x HDMI Type-A (HDMI 1.4b)
USB (UVC) Inputs: 2 x USB-C
HDMI Outputs: 2 Configurable (Preview, Program, Multiview, Inputs 1–6)
Input Frame Rates: 1080p (23.98–60 fps), 1080i (25, 29.97, 30 fps)
Output Frame Rates: 1080p (24, 25, 30, 50, 60 fps)
Video Streaming Standards: 1080p (23.98–60 fps)
HDMI Input Color Space: 4:4:4 RGB, 4:4:4 YUV, 4:2:2 YUV / 8, 10, 12-bit
USB Input Color Space: 4:2:2 YUV, 4:2:0 YUV (NV12)
HDMI Output Color Space: 4:4:4 RGB, 4:4:4 YUV / 8-bit
USB Output Color Space: 4:2:2 YUV / 8-bit
Format/Frame Rate Converters: On All HDMI and USB Inputs

Switching Specifications
Total Layers: 9 Simultaneous (Preview and Program)
Downstream Keyers: 2
Chroma Keyers: 2 (Green and Blue)
Luma Keyer: 1
Media Players: 2 Simultaneous
Transitions: SMPTE Wipes, Dip, Fade
Preview: True Preview with Complete Scene/Overlay Display
Generated Borders: All Scenes
Multiview Display: Program/Preview, Live Inputs, Scene/Media Thumbnails, Mixer, Status
Supported Media: MP4 (Video), PNG/JPG (Images), WAV (Audio)
Bluetooth: 5.3 (Stereo Audio Input or Phone Calls)

Audio Input/Output
Analog Inputs: 2 x Neutrik Combo Jacks (Mic/Line/Instrument)
Digital Inputs:
USB 1 – 2-in/2-out or 20-in Multichannel
USB 1 Chat – 2-in/2-out with Mix-Minus
USB 2 – 2-in/2-out with MFi Support
USB 4 & 5 – RØDE USB Mics and RØDECaster Pro II/Duo
Wireless Inputs: 2 x Series IV Wireless Receivers
Analog Outputs: 2 x 1/4-inch Headphones, 2 x 1/4-inch Balanced Line (L/R)
Audio Mixer: 20 Sources, 9 Stereo Channels Simultaneously
Audio Outputs: 14 Custom Routable Outputs (USB, HDMI, Network, Headphones, Recording, etc.)

Preamps
Type: Revolution Preamps™
Gain: Up to 76 dB
Frequency Response: 20 Hz – 20 kHz
EIN: –131.5 dBV (A-weighted)

Audio Processing
Channel Processing: APHEX® VoxLab™
Advanced Per Channel: Compressor, EQ, De-esser, Noise Gate, HPF, Aural Exciter™, Big Bottom™, Panning
Streaming Format: 48 kHz / 32-bit
Recording Format: 48 kHz / 24-bit

Recording & Streaming
Streaming Protocols: RTMP/RTMPS over Wi-Fi or Ethernet
Supported Platforms: YouTube Live, Twitch, Facebook Live, Twitter/X, Custom Server
Storage: External USB Mass Storage (exFAT)
Program Video Recording: H.264/AVC MP4 with AAC Stereo Mix
ISO Video Recording: 6 Video Inputs + Program Feed (up to 1080p30)
Stereo Audio Recording: WAV
Multitrack Audio Recording: 9 Independent Stereo WAV Files

Connectivity & Software
Network: Ethernet (10/100/1000 BaseT), Wi-Fi 6 (2.4 & 5 GHz)
NDI Support: 4 Inputs + 1 Output (TCP, Multicast)
NDI Video Codecs: H.264, HEVC/H.265, 4:2:0 8-bit
NDI Audio Codecs: AAC-LC, L-PCM Stereo 2.0 @ 48 kHz
Control App: RØDECaster App for Scene Building, Mixer Control, Auto-Switching, Routing, Streaming Profiles
Operating System Support: macOS 11+, Windows 10 (1803+), Windows 11
