DIGITAL AUDIO DENMARK

MOD-DANTE

Expansion Cards

128 ch Dante/AES67 I/O, 44.1–192 kHz, bidirectional SRC, dual Ethernet, 128 Dante flows, AES67 with SAP, Dante Domain Manager support.

Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The MOD-DANTE is a purpose-built expansion module designed to integrate Dante and AES67 audio networking directly into compatible Digital Audio Denmark units. When installed, it provides seamless access to 128 bidirectional channels at standard sample rates, enabling robust, scalable, and flexible AoIP (Audio over IP) connectivity for modern production environments. Whether you're working in studio recording, broadcast, or live sound, the MOD-DANTE empowers your system to connect effortlessly with other Dante or AES67-enabled devices.

One of the module’s standout features is its built-in bidirectional sample rate conversion, which allows you to bridge networks that operate with different clocks or sample rates such as unsynchronized Dante and AES67 systems. The MOD-DANTE also supports Dante Domain Manager and AES67 with SAP discovery, ensuring easy integration into both advanced and legacy network infrastructures. Its dual RJ45 Ethernet ports can be configured for either switched or redundant operation, providing added resilience for mission-critical setups. With scalable channel counts based on sample rate and latency settings adjustable up to 21 milliseconds, the MOD-DANTE delivers both performance and flexibility in one compact module.

Features

Activates Dante and AES67 Connectivity
Enables network audio streaming for compatible devices using the Dante and AES67 protocols.

Supports 128 Channels
Delivers up to 128 input and 128 output channels at 44.1 or 48 kHz sample rates.

Built-In Sample Rate Conversion
Bridges networks running at different sample rates or unsynchronized clocks.

Dual Ethernet Ports
Offers switched or redundant network connections for stable and secure operation.

Supports Dante Domain Manager
Fully compatible with centralized Dante management for enterprise-level control.

AES67 Ready with SAP Discovery
Ensures interoperability with other AES67 devices and simplifies setup with automatic device discovery.

Scales with Sample Rate
Channel count adjusts based on higher sample rates for efficient network use.

Compact and Modular
Fits into expansion slots of compatible devices, enhancing flexibility without adding bulk.

Specifications

General Specifications
Device Type: Dante/AES67 Network Audio Interface Module
Model: MOD-DANTE
Function: Enables Dante and AES67 connectivity in compatible DAD/NTP devices
Channel Capacity: 128 Input + 128 Output Channels @ 44.1 / 48 kHz
Compatibility: Dante (Audinate Ecosystem), AES67 (with SAP Discovery)
Dante Flows: Up to 128 Bidirectional Flows
Sample Rates Supported: 44.1 kHz to 192 kHz
Channel Scaling:
– 128 ch @ 44.1 / 48 kHz (1FS)
– 64 ch @ 88.2 / 96 kHz (2FS)
– 32 ch @ 176.4 / 192 kHz (4FS)
Clocking: Synchronization to Dante Clock or Internal System Clock
Dante Domain Manager: Supported

Networking
Ports: 2 x RJ45
Mode: Switched or Redundant (User-Configurable)
Connection Type: IP-Based Ethernet (AoIP)

Sample Rate Conversion (SRC)
SRC Capability: Bidirectional (Jointly Selectable for Input and Output)
SRC Latency:
– Input (48→96 or 96→48): ≈ 0.8 ms
– Output (48→96 or 96→48): ≈ 1.1 ms

Installation
Slot Requirement: Modular Card Slot in Compatible DAD/NTP Devices
SKU: MOD-DANTE

Use Cases
Bridge Between Unsynchronized Dante/AES67 Networks
Connect Systems with Different Sample Rates
High-Density Audio-over-IP Routing
Expandable Up to 1024 Channels Using 8 Cards
