EARTHWORKS

M50

Condenser Microphones

Omnidirectional, 3Hz–50kHz flat response, 140dB SPL, low noise, 24–48V phantom, XLR output, ideal for loudspeaker design, PA tuning, and acoustic analysis

$1,450.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The Earthworks M50 is a premium-grade 50kHz omnidirectional measurement microphone, expertly crafted for professionals who demand the highest level of accuracy in audio measurement and analysis. With its exceptionally flat frequency response from 3Hz to 50kHz, the M50 offers unparalleled transparency and precision, making it ideal for a wide range of high-end applications including loudspeaker design, acoustic research, ultrasonic/subsonic transducer testing, and PA system alignment.

What sets the M50 apart is its combination of blazing-fast impulse response, linear phase performance, and remarkably low distortion, even at sound pressure levels up to 140dB. This level of detail is critical when capturing transient-rich content or analyzing fine spectral information that contributes to our perception of timbre and texture. Built with temperature-compensated electronics for consistent performance across changing environments, and compatible with top measurement platforms like SMAART™, SIM™, REW™, FuzzMeasure™, and more, the M50 is an indispensable tool for engineers, designers, and researchers alike.

Each unit includes a printed frequency response chart and a downloadable Electronic Calibration File (ECF) for precise, software-integrated measurement calibration. Whether you're developing the next generation of high-end audio systems or conducting sensitive acoustical studies, the M50 delivers reliability, accuracy, and reference-quality performance in a compact, rugged design.

Features

Ultra-Wide Frequency Response
Captures extreme detail from 3Hz to 50kHz, making it ideal for high-resolution acoustic measurements.

Precision Omnidirectional Pickup
Delivers a consistent, accurate response in all directions for true free-field measurement.

Exceptional Clarity and Speed
Lightning-fast impulse and linear phase response ensure unmatched time-domain accuracy.

Built for Professional Analysis
Perfect for loudspeaker design, PA system alignment, scientific research, and ultrasonic testing.

High SPL Handling
Accurately measures up to 140dB SPL without distortion, suitable for loud environments.

Temperature-Compensated Electronics
Delivers reliable, repeatable results across varying environmental conditions.

Software-Compatible and Calibrated
Pairs seamlessly with popular measurement software and includes a downloadable Electronic Calibration File.

Specifications

General Specifications
Device Type: Precision Measurement Microphone
Application: Loudspeaker Design, Scientific Research, Ultrasonic/Subsonic Measurements, System Alignment
Polar Pattern: Omnidirectional
Frequency Response: 3 Hz – 50 kHz
Impulse Response: Lightning Fast
Phase Response: Linear
Calibration: Individually Tuned with Electronic Calibration File (ECF)
Compatibility: SMAART™, SIM™, REW™, Electroacoustics Toolbox™, FuzzMeasure™, and Other FFT-Based Measurement Software

Performance
Sensitivity: 34 mV/Pa (–29 dBV/Pa)
Max Acoustic Input: 140 dBSPL
Equivalent Noise: 20 dB SPL (A-Weighted)
Temperature Compensation: Yes
Handling Noise: None

Power
Phantom Power Requirements: 24–48V, 10 mA

Input/Output
Output Connector: XLR (Pin 2 Positive)
Output Impedance: 65 Ω Balanced (Between Pins 2 & 3)
Minimum Output Load: 600 Ω

Physical
Dimensions (L x D): 229 mm x 22 mm (9.0" x 0.860")
Weight: 0.5 lb (225 g)
