Allen & Heath AHM-64
MPN #AHM-64
$3330.00
Save 43.1%, MSRP $5849.00
64-64 matrix, 12-12 analog I/O, AEC support, Dante/SLink 128-128, 96kHz core, 64 zones, 32 user profiles, AMM, ANC, GPIO, Crestron/Extron ready
Designed for the most demanding and expansive installations, the Allen & Heath AHM-64 stands at the top of the AHM series with a powerful 64-64 processing matrix. Capable of managing up to 64 zones and integrating with up to 96 remote controllers, it's a perfect fit for large venues, multi-room facilities, campuses, and enterprise-scale projects.
Equipped with 12 analog mic/line inputs and 12 relay-protected outputs, the AHM-64 also supports advanced audio networking via an I/O port that accepts Dante, MADI, Waves, or SLink cards. A built-in 128x128 SLink port offers further system expansion potential, allowing seamless integration of remote I/O and mixing components.
Its comprehensive DSP toolkit includes 8 automatic mic mixers, ambient noise compensation (ANC), priority ducking, extensive EQ, dynamics, delay, and speaker-specific processing. It's also AEC-ready for professional teleconferencing, with an optional module that provides multiple channels of acoustic echo cancellation.
The AHM-64 runs on a 96kHz FPGA core for ultra-low latency performance and supports extensive system customization. It features TCP/IP integration for third-party control (Crestron, AMX, Extron), a range of remote controller compatibility, 32 user profiles, and front-end user control via Custom Control apps. A DC backup power supply option ensures uninterrupted operation, making the AHM-64 an incredibly robust solution for mission-critical AV environments.
Features
Scalable 64-64 Matrix: Full routing and processing across 64 inputs and 64 outputs, ideal for expansive installations.12-12 Local Analog I/O: Includes 12 mic/line inputs and 12 relay-protected line outputs via Phoenix connectors.Advanced Networking Options: Supports Dante, MADI, Waves, and includes built-in 128-128 SLink expansion port.Comprehensive Zone Processing: Each input and output offers 8-band PEQ, dynamics, delay, crossover, limiter, and all-pass filters.Powerful DSP Tools: Includes 8 automatic mic mixers, ambient noise compensation, ducking, and EQ ganging.Acoustic Echo Cancellation (AEC): Optional multi-channel AEC module tailored for conferencing and communication applications.System Control & Integration: Works with IP1, IP6, and IP8 controllers, and integrates with third-party systems (Crestron, AMX, Extron).32 User Profiles & Event Scheduler: Customizable access and automation for large teams or complex schedules.Front-End Software & BYOD: Manage with Mac/Windows software or control via Custom Control app on user devices.Reliable Performance Core: 96kHz FPGA engine delivers ultra-low latency and stable audio performance.Backup Power Ready: Includes DC backup input for uninterrupted operation.
Specifications
Signal Processing
64-64 processing matrixConfigurable mono/stereo zones or speaker processing8x automatic mic mixersAcoustic Echo Cancellation (AEC) module for multiple channelsAmbient Noise Compensation (ANC)Priority ducking8-band PEQ, dynamics, and delay on all inputs and zonesOutput speaker processing: crossover filters, delay, limiter, PEQ, and all-pass filtersEQ ganging: Relative, Absolute, and Mirrored controlsProcessing expansion module
Inputs & Outputs
12x mic/line inputs (Phoenix connectors)12x relay-protected line outputs (Phoenix connectors)2-2 local GPIOBuilt-in 128-128 SLink port for expansionAudio networking I/O port (up to 128-128 channels)Optional networking cards: Dante (96kHz, AES67, DDM ready), MADI, Waves, SLink
Hardware Features
96kHz FPGA core with ultra-low latencyIntegrated stereo playbackEvent scheduler32 user profilesDC backup power supply support
Remote Control & Integration
Compatible with IP1, IP6, IP8 remote controllersTCP/IP protocol for third-party integrationNetworkable GPIO interfaceCrestron, AMX, and Extron control driversCustom Control app and editor for BYODMac and Windows AHM System Manager software
Application Scope
Ideal for large-scale multi-zone, multi-room installationsSuitable for campus-wide AV integration, corporate buildings, large hospitality venues, and educational institutionsTailored for AV conferencing environments with extensive AEC support
