Allen & Heath Avantis
MPN #avantis
The third mixer based on our 96kHz XCVI FPGA engine. Avantis puts all our next-generation technology in a 64 channel / 42 configurable bus console with dual Full HD touchscreens,
a super-flexible workflow with Continuity UI, extensive I/O options, add-on processing from our flagship dLive mixing system, and a rugged full metal chassis.
The power of Avantis emanates from the XCVI Core - pioneered by the Allen & Heath R&D team using next generation FPGA technology, with parallel virtual processing cores generating enough power for 88x42 (including FX returns) channels of processing at 96kHz sampling rate.
The massive power of XCVI (25 billion operations per second) allows Avantis to deliver 64 full processing inputs and 12 stereo FX returns, 42 bus with configurable mix architecture, variable bit depth for ultimate precision and noise performance, a virtually infinite mix headroom thanks to a 96bit accumulator, and class-leading latency at an ultra-low 0.7ms.
Features
96kHz 64 channel / 42 bus digital mixerXCVI FPGA core with ultra-low latency (0.7ms)Fully configurable mix bus architectureSuper-tough, full metal chassisContinuity UI seamlessly connects physical and touchscreen controls for the fastest, most intuitive workflowsdPack option adds dLive processing, including 16 Dyn8 engines, plus per-channel zero-latency DEEP Compressors and Dual-Stage Valve preamp12 RackExtra FX slots with dedicated stereo returns16 DCAsDual 15.6" Full HD capacitive touchscreens with gesture controlAMM (Automatic Mic Mixer) up to 64 channels across 1, 2 or 4 zonesFully assignable layout144 fader strips (24 faders, 6 layers) with optional dedicated master sectionSLink port for connection to Remote I/O Expanders and the ME Personal Mixing System12 analogue XLR Inputs / 12 analogue XLR Outputs1 Stereo AES In / 2 Stereo AES Out2 I/O Ports, both capable of 128x128 operation at 96kHz - for optional cards inc. Dante, MADI and gigaACEUser configurable rotary controls24 assignable SoftKeysComprehensive metering with multi-point peak detectionUSB stereo recording and playbackBNC Word Clock
