The newest version of the award-winning BOX Console provides even more options and flexibility for modern studio workflow
Offering a total of eight input channels and eight 500 Series slots, the updated BOX Console also features LED metering for each of its 24 summing channels. The new BOX Console provides the same comprehensive rear panel connections, full center section and monitoring as its predecessor, as well as the 0dB bypass switch on each summing channel - a feature so popular it was included in the design of API's new 1608-II and 2448 consoles.
THE BOX is API's small-format solution for any studio where space or budget is limited. Using the same circuitry and components as all other API consoles (including the Vision and Legacy AXS), THE BOX provides the signature analog sound and performance users have come to expect from API. Designed and optimized for the digital era, THE BOX handles all the functions needed for production not provided by most DAWs, including mic preamps, input signal processing, high-quality mix bus, cue sends with talkback, monitor control and more. Most importantly, THE BOX offers the legendary API sound in an efficient, cost-effective package.
Eight (8) input channels with Mic Preamp, Line Input and Hi Pass FilterEight (8) 500 Series slots (1 per input channel)Direct Out on Input ChannelsOn-Board Stereo Bus Compressor w/ ability to assign to program bus or input channels 1-4Instrument Direct Inputs on channels 1-4Sixteen (16) summing channels (24 channels during mix)0dB bypass switch for each summing channel4-Segment LED Metering on each summing channelStereo program bus with master fader, insert, and external inputOne (1) stereo and (2) mono auxiliary sends/busesStereo cue send/bus & headphone systemPFL, AFL, and Solo-In-Place solo modes with stereo solo busFull-featured monitor section that supports two stereo monitor systemsTalkback systemComprehensive rear panel connections with balanced inputs and outputsIntegrated power supply
