Apogee Symphony I/O 8X8MP-2X6SE
UPC/EAN #805676303147
MPN #SYM2-8X8MP-2X6SE
8 mic/line, 2 line in, 14 line out, AES/optical/SPDIF coax, premium AD/DA, modular I/O, touchscreen, Thunderbolt, immersive audio support
The Symphony Mk II - 8 Mic/Line x 2 Line In x 14 Line Out + AES/Optical/SPDIF Coax (Symphony I/O 8X8MP-2X6SE) is a premium audio interface built for demanding studios seeking both pristine sound quality and flexible connectivity. This configuration pairs Apogee's acclaimed 8-8 MP module"featuring 8 world-class microphone preamps-with the 2-6 Special Edition module, which adds ultra-transparent conversion for two additional line inputs and 14 line outputs. It's a tailored setup ideal for hybrid workflows, giving engineers extensive analog I/O alongside powerful digital routing options.
Designed with Apogee's legendary AD/DA conversion, this unit delivers high-fidelity sound for tracking, mixing, and mastering. The inclusion of AES, optical (ADAT/SPDIF), and coaxial S/PDIF ensures full digital integration, making it compatible with virtually any studio setup. Combined with Thunderbolt, Pro Tools + Dante, or Waves SoundGrid connectivity, the Symphony Mk II 8X8MP-2X6SE becomes a centerpiece of any high-end production environment, offering seamless control, minimal latency, and expansive I/O for modern music and audio post-production workflows.
Features
Includes 8 premium mic/line inputs with built-in mic preamps.Adds 2 dedicated line inputs and 14 high-quality line outputs.Supports AES, optical, and coaxial SPDIF digital formats for flexible digital routing.Delivers industry-leading AD/DA conversion for top-tier sound clarity.Features a responsive touchscreen for intuitive control and metering.Ideal for immersive audio formats like Dolby Atmos with up to 32 speaker outputs.Offers ultra-low latency performance with modular I/O flexibility.Compatible with Thunderbolt, Pro Tools + Dante, or SoundGrid systems.Built in the USA for professional studio reliability.
Specifications
General Specifications:
Product: Apogee Symphony I/O Mk IIModel: Symphony I/O 8X8MP-2X6SEConfiguration: 8 Mic/Line Inputs, 2 Line Inputs, 14 Line Outputs, AES/Optical/SPDIF Coaxial I/OConnectivity Options: Thunderbolt, Pro Tools Plus (Dante and Pro Tools), Waves SoundGridModular I/O: Supports up to 32 channelsDisplay: Intuitive touchscreenPower: 90-240VAC, 50-60Hz, 150WPlatform Compatibility: Thunderbolt - Mac OS 10.10 and above; Pro Tools HD/HDX - Mac or PC with Pro Tools HD 9 or later; Dante - PC compatible
Analog to Digital Conversion:
THD plus N: -115 dB at 22 dBu (0.00020 percent) unweightedDynamic Range: 122 dB A weightedMaximum Input Levels: +24 dBu at +4 dB setting, +6 dBV at -10 dB settingFrequency Response: 44.1 kHz to 20 kHz (+/- 0.05 dB)Input Impedance: 10 kilo ohms
Digital to Analog Conversion:
THD plus N: -119 dB at 21 dBu (0.00014 percent) unweightedDynamic Range: 126 dB A weightedMaximum Output Levels: Infinity to +24 dBuFrequency Response: DC to 20 kHz (+/- 0.05 dB)Output Impedance: 50 ohmsOutput Design: Balanced through Apogee Perfect Symmetry Circuitry
Headphone Output:
Connector: 1 stereo 1/4 inch on front panelTHD plus N: -110 dB at 19 dBu into 600 ohms, -101 dB at 14 dBu into 32 ohmsDynamic Range: 121 dB A weightedOutput Technology: Apogee Constant Current Drive
I O Modules:
Mic Pres: 8 Mic/Line combo inputs with digitally controlled preampsLine Inputs: 2 additional balanced line inputsLine Outputs: 14 balanced line outputsAES Digital I O: AES inputs and outputsOptical I O: ADAT and SMUX supportSPDIF I O: Coaxial SPDIF input and output
Additional Features:
Immersive Audio: Support for Dolby Atmos, Sony 360 Reality Audio with up to 32 speaker outputsLow Latency: Ultra-low latency performanceSoftware Control: Integrated Symphony Control softwareDesigned and Manufactured: In the USA
