UPC/EAN #6971842181230     MPN #APA0131A20


Free shipping in Canada. Conditions

60W daylight focusing LED fixture with 8 preset special effects, active cooling, onboard & app control and 15 to 45° adjustable beam angle

The LS 60d is a battery-powerable daylight-balanced focusing LED that uses custom aspherical optics to achieve a 15-45° spot-flood beam angle with intense output and flexibility.

The LS 60d punches way above its weight class as a 60W Daylight Focusing LED fixture that's up to par with the output of a 650W tungsten Fresnel and blows away comparable LED lights. With its custom, Aputure aspherical optics, the LS 60d can output 50,000+ lux in full spot, or 8,300+ lux in flood mode.

The LS 60d Daylight LED continues Aputure's ambition to provide high-quality, color-accurate LEDs to all filmmakers, with CRI/TLCI scores of 95+ and an SSI (D56) of 72.

Designed to withstand the rigors of any film set, the LS 60d lamp head &DC power connector feature a weather-resistant design as a sign of its durability, so filmmakers can feel free to take it on any adventure.

With a variety of included power solutions, the LS 60d is a light designed to solve problems in ways no other fixture can. The modular V-Mount Receiver on its yoke can hold all of its power options, including the AC adapter, D-Tap (V-Mount) Batteries, and the intelligent Dual NP-F Battery Plate.

Light Storm fixtures like the 120d II, 300d II, and 300x can be powered using only a single battery, and the LS 60d is no different. The LS 60d can achieve full output with a single D-Tap battery or two NP-F batteries, or half output with a single NP-F battery, using its intelligent Dual NP-F Battery Plate.

Included with the LS 60d, the 8-Leaf Barndoors allow for more precise control than traditional barndoors due to the two pairs of helper flags that can adapt the light output's size and shape.

As a Light Storm fixture, the LS 60d can utilize a wide variety of lighting modifiers. In addition to its 8-Leaf Barndoors, 60d includes a custom Bowens Mount Adapter that attaches to its accessory mount and allows it to use Bowens Mount soft light modifiers.

The LS 60d is also compatible with the LS 60 Softbox, a square soft light modifier, and the Spotlight Mini Zoom, a precision protection attachment with a 2X optical zoom range, both of which are designed specifically for the LS 60d & 60x.

The 60d launches with 8 built-in lighting FX, such as Paparazzi, Fireworks, Lightning, Faulty Bulb, TV, Pulsing, Strobe, and Explosion.

Joining the Sidus Link ecosystem, the LS 60d gains unprecedented, quick & easy wireless control for any fixture in its class. As part of a mesh network, the LS 60d conducts two-way communication with the controlling smartphone or tablet and all other Sidus Mesh fixtures, resulting in a more robust network and longer range.
  • Output: 54,300 Lux at 3.3' (15°, 5600K)
  • 5600K CCT
  • 15 to 45° Adjustable Beam Angle
  • AC or Battery Power
  • Onboard & App Control
  • CRI 96 | TLCI 98 | CQS 93 | SSI 72
  • Active Cooling, Weather-Resistant Design
  • 8 Preset Special Effects
  • Includes Bowens Adapter, Barndoors & Bag
  • CCT 5600K
  • CRI ?96
  • TLCI ?98
  • CQS 93
  • SSI (D56) 72
  • Beam Angle 15°~45°
  • Output Wattage 60W
  • Max Power Draw 90W
  • Operating Current <6.5A (Max)
  • Operating Voltage (Power Supply) 19V
  • Operating Voltage (Battery) Sony NP-F 6~8.4V (Single battery) 12~16.8V (Dual battery)
  • Operating Voltage (Battery) D-Tap 12 ~ 16.8V
  • Operating Temperature: -20°C ~ 45°C / -4°F ~ 113°F
  • Control Methods: On-board, Sidus Link (Sidus MeshTM)
  • Wireless Operating Range (Bluetooth): ? 80m / 262.5ft
  • Screen Type: OLED
  • Weatherproofing: Yes
  • Cooling Method: Active Cooling
  • Cable Type: Head Cable: 4-pin DC Twist Lock Cable
  • Cable Type: Power Cable: Locking IEC Power Cable (4m)
  • Accessory Mount: LS 60 Mini Mount
  • Accessory Mount Diameter: 120mm / 4.72in

  • Photometrics
  • 15° at 5600K: 5044 fc / 54,300 Lux at 3.3' / 1 m, 706 fc / 7602 Lux at 9.8' / 3 m, 252 fc / 2715 Lux at 16.4' / 5 m
  • 45° at 5600K: 837 fc / 9014 Lux at 3.3' / 1 m, 101 fc / 1096 Lux at 9.8' / 3 m, 37 fc / 402 Lux at 16.4' / 5 m

  • Lamp Head without Yoke: 209*116mm / 8.23*4.57in
  • Lamp Head with Yoke: 280*156*127mm / 11.02*6.14*5in
  • Barn Doors Closer: 134*108*33mm / 5.28*4.25*1in
  • Power Supply: 135*56*34mm / 5.31*2.2*1in
  • NP-F Battery Plate: 103*87*25mm / 4.06*3.43*1in
  • Case: 420*200*200mm / 16.54*7.87*8in

  • Lamp Head: 1.8kg / 3.968lbs
  • Barn Doors: 222g / 0.489lbs
  • Power Supply: 370g / 0.816lbs
  • NP-F Battery Plate: 134g / 0.295lbs
  • Total w/ Case: 4.475kg / 9.866lbs
