Atomos A-Eye 4K-12X - PTZ Camera
MPN #ATOM-AE4K12
4K AI PTZ camera, 12x optical zoom, 170 degree pan, 30 to 90 degree tilt, auto tracking, HDMI SDI USB IP, PoE plus, 1 over 2.8 inch CMOS, 16x digital zoom, 71 to 8.2 degree FOV
The A-Eye 4K-12X PTZ Camera is an AI-powered UHD camera designed for effortless professional video production. With a 1/2.8-inch CMOS sensor, 12x optical zoom, and precise pan/tilt motion, it automatically tracks subjects with smooth, intelligent framing-ideal for classrooms, corporate presentations, worship services, and live events.
Offering crystal-clear 4K output, advanced noise reduction, and wide connectivity including HDMI, SDI, USB, and IP streaming protocols such as NDI HX3, RTMP, and SRT, the A-Eye 4K-12X integrates seamlessly into modern workflows. Its robust build and versatile mounting options make it a reliable solution for scalable, operator-free production in any environment.
Caractéristiques
AI-Powered Tracking: Automatically follows the speaker or subject with smooth, precise PTZ movement.Ultra HD Video: 1/2.8" CMOS sensor with resolutions up to 4Kp60 over HDMI and 1080p over SDI/USB.12x Optical Zoom + 16x Digital Zoom: Wide 71 degree field of view down to 8.2 degree for tight framing.Flexible Connectivity: HDMI, 3G-SDI, USB, and IP streaming with support for RTMP/S, SRT, RTSP, ONVIF, and NDI|HX3.Professional Streaming Options: Dual-stream output with H.264/H.265 compression for efficient delivery.Audio Integration: Line in/out with HDMI and USB audio support (no built-in mic).Wide Control Compatibility: RS-232, RS-485, VISCA, Pelco-D, Pelco-P, and UVC over USB.Flexible Installation: Wall mount rack, remote control, and PoE+ power included for easy setup.Preset Management: Up to 255 positions with 0.1 accuracy for fast recall in live production.Quiet, Precise Motion: Variable pan/tilt speeds (up to 100/s pan) with image flip and freeze support.Built for Hybrid Workflows: Perfect for classrooms, houses of worship, corporate presentations, and live streaming events.
Spécifications
General Specifications
Model: A-Eye 4K-12X PTZ CameraSensor: 1/2.5 inch CMOS 8.51 MPLens: 12x optical zoom f = 4.4 " 52.8 mm F1.8 " F2.6Digital Zoom: 16xMinimum Illumination: 0.5 Lux F1.8 AGC ONShutter: 1/30 " 1/10000 sSNR: greater than or equal to 55 dBDNR: 2D and 3D
Mechanical
Pan Angle: plus minus 170 degreesTilt Angle: minus 30 degrees to plus 90 degreesPan Speed: 1.7 " 100 degrees per secondTilt Speed: 1.7 " 69.9 degrees per secondPresets: 255 accuracy 0.1 degreeHorizontal FOV: 71 " 8.2 degreesVertical FOV: 42.7 " 4.5 degrees
Video
Scanning: ProgressiveHDMI Output Resolutions: up to 4K at 60 fps and formats down to 720p3G SDI Output Resolutions: up to 1080p60 and formats down to 720pCompression: YUY2 H.264 MJPEG H.265Formats: YUY2 max 1080p at 5 fps H.264 H.265 MJPEG max 2160p at 30 fps
Network Streaming
First Stream Resolutions: up to 3840x2160Second Stream Resolutions: up to 720x480Video Bitrate First Stream: 32 kbps to 51200 kbpsVideo Bitrate Second Stream: 32 kbps to 20480 kbpsControl: CBR or VBRFrame Rate: up to 60 fps at 60 Hz or 50 fps at 50 HzAudio Compression: AAC at 96 128 or 256 kbpsProtocols: NDI HX3 TCP IP HTTP RTSP RTMP RTMPS ONVIF DHCP SRT Multicast
Audio I O
Input: Line In 3.5 mmOutput: Line Out 3.5 mm HDMI USBNo built in microphone
Control Interfaces
RS 485: 2 pin Phoenix max 1200 m VISCA Pelco D Pelco PRS 232 In: 8 pin Mini DIN max 30 m VISCA Pelco D Pelco PRS 232 Out: 8 pin Mini DIN VISCA network onlyUSB: USB 2.0 Type A supports UVC 1.1 1.5 and PTZ control
Connectivity
Ethernet: 10 100 MbpsSDI: 3G SDI BNC 800 mVp p 75 Ohm SMPTE 424MHDMI: HDMI version 1.3Power Input: DC 12V JEITA type or PoE plus 802.3atPower Consumption: Max 18 W
Physical
Dimensions W x H x D: 146 x 169 x 168 mmWeight: 1.6 kgOperating Temperature: up to 40 degrees CelsiusBody: ABS
Indicators
Tally Light: YesPower On Indicator: Yes
Package Contents
A-Eye 4K-12X PTZ cameraRS 232 serial cable 2 mUSB 3.0 A A cable 1.5 mLens coverRemote controllerAccessory trayWall mount rackScrew packPower adaptor with 4 plugsQuick Start Guide
Warranty
1 year standard2 years with product registration
