MPN #EVO16


Save 11.6%, MSRP $859.00
Financing available
Free shipping in Canada. Conditions

24in | 24out Audio Interface

Make recording easy
Eight award winning EVO Preamps alongside our advanced converter technology will make everything you do, sound better. Add to that, intelligent mic preamps that set their own levels with Smartgain, the all new, groundbreaking Motion UI control system, and enough I/O firepower to tackle even the biggest of sessions, EVO 16 is truly a studio powerhouse, designed from the ground up to make recording easy.

Get studio quality recordings
Level up your audio performance with eight sonically stunning EVO Preamps. Backed by 25 years of engineering experience, our analogue mic preamp has been designed to deliver the most accurate, clean, and true to source version of your audio, no matter what you're recording.

Our EVO Preamp technology not only has all the sonic advantages of an analogue mic preamp, but combines it with digitally controlled precision, giving you the ability to set your gain with pin-point accuracy, right down to the decibel.

A total gain-changer
Make recording drums and larger sessions easy with Smartgain. Automatically set the gain for all 8 channels at once with a simple touch of a button. Powered by our lightning quick Smartgain algorithm, Smartgain uses advanced peak analysis to automatically analyse, adjust and set your gain to the perfect levels " all in less than 20 seconds!
  • 8 x EVO Mic Preamps
  • 2 x JFET Instrument Inputs
  • 2 x Independent Headphone Outputs
  • 8 x Line Outputs
  • 2 x Optical Inputs
  • 2 x Optical Outputs
  • Multi-Channel Smartgain
  • ?EVO Motion UI' Control System
  • Programmable Function Button
  • Ultra-Low Latency Software Mixer
  • Monitor Control
  • Audio Loop-back
  • Word Clock Output
  • Standalone Mode
  • USB2.0 (USB-C Connection)
  • 24bit / 96kHz
  • Microphone Preamplifier
    Mic Gain Range: 58dB
    Line Gain Range: 58dB (-10dB pad)
    Phantom Power: 48v +/-4v @ 10mA/Channel
    Mic EIN: <-127.5dBu
    CMRR: >80dB @ 1kHz
    Maximum Input Level: +16dBu
    Input Impedance (Mic): >3k? Balanced
    Input Impedance (Line): >10k? Balanced
    Frequency Response: +/-0.5dB 10Hz to 40kHz
    Crosstalk: <-105dBu @ 1kHz <-103 @ 10kHz
    THD+N @ 0dBu (1kHz): <0.0015%
    SNR: 100dB
    XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
    1/4" Jack: IP (Hot), RING (Cold) & SLEEVE (Shield)

    D.I Gain Range: 58 dB
    Maximum Input Level: +10dBu
    Input Impedance: 500k
    Frequency Response +/-0.5dB 10Hz to 20kHz
    THD+N @ 0dBu (1kHz): <0.1%
    SNR: 100dB
    1/4" Jack: TIP (Hot) & SLEEVE (Shield)

    ADC Inputs
    Digital Reference Level: 0dBFS = +10.5dBu
    Frequency Response: +/-0.5dB 10Hz to Fs/2
    Crosstalk: -125dBu @ 1kHz & 10kHz
    THD+N @ -1dBFS (1kHz): <0.001%
    Dynamic Range: 112.5dB A-Weighted

    DAC Outputs
    Maximum Output Level: 12dBu
    Digital Reference Level: 0dBFS = +12dBu
    Output Impedance: <50?
    Frequency Response: +/-0.5dB 10Hz to Fs/2
    Crosstalk: <-110dBu @ 1kHz
    THD+N @ -1dBFS (1kHz): <0.001%
    Dynamic Range: 121dB A-weighted
    1/4" Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)

    Headphone Output
    Max Output Level: 11.25dBu
    Output Impedance: <50?
    Frequency Response: +/-0.5dB 10Hz to Fs/2
    Crosstalk: -108dBu @ 1kHz
    THD+N @ -1dBFS (1kHz): <0.001%
    Dynamic Range: 118dB A-weighted
    Max Level Into 30ohms: +8.5 dBu, 0.00094% THD+N, 1.66Vpk Power: 86mW
    Max Level Into 60ohms: 10 dBu, 0.00079% THD+N, 2.55Vpk Power: 104mW
    Max Level Into 600ohms: 11.2 dBu, 0.00057%THD+N, 3.83Vpk Power: 24mW
    1/4" Jack: TIP (Left), RING (Right) & SLEEVE (Shield)

    Dimensions (Unit) 355mm (w) x 255mm (d) x 53mm (h)
