The entire Studio Economik's website is now priced in Canadian Dollars only.

$689.00

Free shipping in Canada. Conditions

Smart Touchpoints enable you to customise your workflow on the fly. Easily route and configure Nero's outputs and monitor controls to create monitoring combinations



Simply hold down a Smart Touchpoint to put it into setup mode, select your routing options and press it again to save.

Inputs
As your studio grows it becomes harder to control. Nero enables you to centralise, connect and control all your monitoring needs from your desktop using Nero's array of stereo inputs.

Outputs
Reference your mixes on up to three sets of speakers, independently set and match volume for all speakers and audition and assign your sub to any monitor path. Nero also provides one dedicated monitor grade headphone amp and three foldback grade headphone amps, making sure you're ready to take on the loudest of sessions with crystal clear headphone mixes.

Assignable Sub
Easily assign a sub to activate when switching to a monitor path of choice but maintain the ability to switch it on and off without losing your saved preset. Nero also lets you audition the sub on any alternative set of speakers without forcing you to assign it permanently

User Defined Dim
Set your attenuation using the volume knob

Latching buttons
Activate Dim, Mono or Talkback with either a tap (latch) or a tap and hold

Tactile Speaker Select
Audition your mixes by quickly switching between monitors

Cue Mix Monitoring
Reference what your artist is hearing and fix problems fast

Sum and Difference
Use this classic trick to quickly hear your stereo information

Smart Mono Mode
Permanently assign a mono speaker without preventing mono functionality on other sources

Features

  • 4x Stereo Analogue sources
  • 2 x Line Level Inputs
  • 1 x Dedicated Cue Mix Input
  • 1 x Aux Input (RCA or Mini Jack)
  • Optical & Coaxial S/PDIF Inputs
  • 3 x Stereo Speaker Outputs
  • 1 x Assignable Sub Output
  • 4x Headphone Outputs with flexible routing
  • Smart Touchpoints for user customisation
  • Talkback Input
  • Internal Microphone
  • External Talkback Input
  • Dim, Cut, Mono & Polarity Monitor Controls
  • Specifications

    BALANCED LINE INPUTS
    NOMINAL INPUT LEVEL: +4dBu
    MAX INPUT LEVEL: +18dBu
    CMRR: > 50dB
    MIC EIN: -128dBu
    CMRR: >80dB @ 1kHz

    UNBALANCED AUX INPUTS
    NOMINAL INPUT LEVEL: -10dBV
    MAXIMUM INPUT LEVEL (minimum trim): +27dBu
    TRIM RANGE: ±12dB

    DIGITAL INPUTS
    INPUTS: TOSLINK and Coaxial
    FORMAT: S/PDIF
    SAMPLE RATES: 44.1kHz - 192kHz
    BIT DEPTH: up to 24bit

    TALKBACK INPUTS
    MAXIMUM IPUT LEVEL: 2dBu
    GAIN: 4-44dB
    PHANTOM POWER: +48V

    SPEAKER OUTPUTS
    MAXIMUM OUTPUT LEVEL: +12dBu

    HEADPHONE OUTPUTS
    MINIMUM LOAD: 12.8Ohms

    PERFORMANCE
    SPEAKER OUTPUTS
    THD+N: 0.0015% 0dBu 1k input
    SNR: 100dBu
    CROSSTALK (SPEAKERS): >100dB
    FREQUENCY RESPONSE: 20Hz - 22kHz ±0.5dB
    ATTENUATION AT MIN VOLUME (SPEAKER OUTPUTS): >110dB

    DAC:
    THD+N: <0.0017%
    DYNAMIC RANGE: 113dB
    FREQUENCY RESPONSE: 20Hz - 22kHz ±0.5dB

    HEADPHONE OUTPUTS
    THD+N @ 0dBu (output level): 0.009% - 30Ohm
    0.009% - 60Ohm
    0.008% - 600Ohm
    PEAK POWER OUTPUT: 90mW - 30Ohm
    56mW - 60Ohm
    7.35mW - 600Ohm
    CROSSTALK: >62dB
    ATTENUATION AT MIN VOLUME: >96dB
    POWER SUPPLY: 12VDC Centre Positive DC Adapter - 2Amps
    Weight: Unit: 2kg
    Dimensions: Unit: 255mm (w) x 75mm (h) x 155mm (d)
    Manufacturer Part Number : Nero

    Reviews

    $689.00

    Free shipping in Canada. Conditions
