The KeyPre was designed for professional keyboard, synthesizer, and drum machine users who want to use something better than a mixer input channel or a DI (direct injection).
Electronic instruments often have a wide range of different output levels and impedances, and with much wider bandwidth than traditional passive instruments such as electric guitars.
This presents a challenge for any outboard device following it. A high performance preamplifier, specifically designed for electronic instruments, is needed to ensure nothing is being compromised or bottlenecked as your sound is being processed.
Over two years have been dedicated to research, test, and develop the KeyPre and we are confident it will preserve the integrity of your electronic instrument for both recording and live applications.
Six independent channelsTRS balanced inputs and output, and additional inputs in the front for up to 12 inputsUses the high performance Ingenius® input stageDirect coupled discrete preamplifierJensen transformer balanced outputUp to 32dB's of GainCan be used with either balanced or unbalanced keyboardsSupports all variety of electronic keyboard or synthesizer output impedancesVery wide frequency response to capture the full bandwidth of your electronic instrumentHigh headroom surpasses even your DAW5 bargraph LED meter which can be custom adjusted internallyInternal international power supplyPatented Xsolate® Ground Lift System to safely isolate output stage ground connectionDesigned and manufactured in the U.S.
Frequency Response: 3Hz - 70kHz
Input Impedance: 48k ohms
Maximum Level before clipping: +28dBu
THD+N: 0.015% @ 10dB Gain
CMRR: 90 dB @ 60Hz
IMD: 0.02% (400Hz, 4kHz)
Noise: -115dB (unfiltered, unweighted)
Dimensions: 19"W x 1.75"H x 8"D
Weight: 8 lbs (3.6kg)
Power requirements: 00-240 VAC, 0.65A, 50/60Hz
Power consumption: 18W
