BAE DMP is a desktop version of the 1073MP. It shares a similar preamp and the same Carnhill (St Ives) transformers as the 1073 and 1084.
All units come standard with the 'Bootsy Collins' mod which consists of a Jensen DI transformer to create the first 1073 direct box. The 1073DMP features include two DI thrus, phase reverse, 48V for phantom power, a built in PSU for extra portability and the same hand-wired modular design that BAE is known for.
Built in PSU for extra portability.
DI in and DI through.
48v for phantom power.
Solid steel chassis.
Same hand-wired modular design that BAE is known for.
10Hz to -3dB at 55kHz Mic Pre Input Impedance
1200 ohms DI Input Impedance
150k ohms Output Impedance
65 ohms Common Mode Rejection Ratio
100dB min @ 60Hz Maximum Output Level
+27.4 dBu @ 600 Power Requirements
115/230 VAC, 28W Gain Voltage
0 to 33.4 Volts Gain dB
0 to 71 dB Equivalent Input Noise
-110 dBu; Unweighted 300kHz Bandwidth Weight
7.3 LBS/3.31 KG Dimensions (Inches)
5.3W x 4L x 11D
