DPA 4188-DP-F-C10-LH
4188 CORE+ Directional Flex Headset Mic, 120 mm Boom, Brown, TA4F Mini-XLR
The DPA 4188 CORE+ Directional Flex Headset Microphone in brown, with a 120 mm boom and TA4F Mini-XLR connector, is a discreet, high-performance solution for live speech and vocal applications. Its comfortable one-ear design combines with DPA's renowned cardioid capsule to provide clear, focused sound with excellent background noise rejection-ideal for presenters, performers, and broadcast talent.
Enhanced with CORE+ technology, this mic delivers ultra-low distortion across the full dynamic range, preserving natural voice tone and detail even at high sound pressure levels. The headset is built to resist humidity and withstand demanding live environments, while the brown finish offers a subtle, low-visibility profile against most skin tones. The TA4F connector ensures seamless integration with a wide range of professional wireless systems, making this headset a dependable choice for uncompromised audio performance.
Features
Focused Cardioid Pickup Pattern: Captures voice with precision while minimizing surrounding noise, ideal for speech and vocals.CORE+ Audio Technology: Delivers ultra-clean, low-distortion sound with enhanced clarity across all dynamics.Discreet and Comfortable Fit: Lightweight one-ear design with a brown finish for a subtle, low-visibility appearance.120 mm Boom Arm: Extended length for precise microphone positioning near the mouth.TA4F Mini-XLR Connector: Ready for wireless systems that support 4-pin Mini-XLR inputs.High SPL Handling: Maintains audio quality even during loud performances or energetic speech.Moisture and Sweat Resistant: Built to perform reliably in live, high-humidity environments.Customizable Fit: Flexible and reversible earset adapts easily for wear on either side.
Specifications
General Specifications
Model: 4188 CORE PlusType: Directional Flex Headset MicrophoneBoom Length: 120 mmColor: BrownMounting Style: Single-ear Flex EarsetConnector: TA4F Mini-XLRCapsule Type: 4088 directional capsule
Audio Performance
Directional Pattern: CardioidPrinciple of Operation: Pressure gradientCartridge Type: Pre-polarized condenserFrequency Response: 20 Hz to 20 kHzSensitivity: 6 mV/Pa, -44 dB re 1 V/PaEquivalent Noise Level A-weighted: Typically 26 dB(A), maximum 28 dB(A)Equivalent Noise Level ITU-R BS468-4: Typically 38 dB, maximum 40 dBDistortion THD less than 1 percent: 134 dB SPL RMS, 137 dB SPL peakMaximum SPL THD 10 percent: 144 dB SPL peakDynamic Range: Typically 111 dB
Electrical Characteristics
Output Impedance from MicroDot: 30 to 40 ohmsOutput Impedance with DAD6001-BC: 100 ohmsCable Drive Capability: Up to 300 meters with DAD6001-BC XLR adapterOutput Balance Principle: Signal balanced with DAD6001-BC XLR adapterCommon Mode Rejection Ratio: Greater than 60 dB from 50 Hz to 15 kHz with DAD6001-BCPower Supply via Adapter: Minimum 5 V, maximum 10 VPower Supply with DAD6001-BC: P48 phantom power, operational from 12 VCurrent Consumption: Typically 1.5 mA microphone only, 3.5 mA with DAD6001-BC
CORE Plus Technology
Distortion Elimination: Minimizes nonlinearities from membrane and electronicsAudio Fidelity: Enhanced clarity and transparency across dynamic rangeTHD Benchmark: Less than 0.5 percentCompatibility: Mixable with non-CORE Plus DPA microphones
Physical Characteristics
Microphone Boom Weight: 0.8 gramsEarhook Weight: 1.1 gramsCable Weight: 6.6 gramsTotal Weight: 8.5 gramsMicrophone Diameter: 5.4 mmCable Length: 1.3 metersCable Diameter: 1.6 mm
Environmental
Operating Temperature Range: Minus 40 to 45 degrees CelsiusRelative Humidity: Up to 90 percentElectromagnetic Compatibility: Fully compliant
Application Suitability
Designed for high-performance vocal and speech applicationsLightweight and unobtrusive for comfort and discretionCan be mounted on either earCompatible with wireless systems using TA4F Mini-XLR connectors
