DPA 4288-DC-F-B00-MH
4288 CORE Directional Flex Headset Mic, 100 mm Boom, Black, MicroDot
Combining the legendary sound of the 4088 Directional Capsule with the lightweight single earset system, the 4288 is ideal for both spoken word and vocal performance applications. It offers accurate and natural voice intelligibility and very high-SPL capabilities " users can both speak and sing into the mic with no hint of distortion.
Features
Pristine audio qualityLightweight and flexibleEasy mounting to the left or rightMinimal visual impactResistant to humidityFlexible adapter system fits most professional wireless systems
Specifications
Directional pattern: CardioidPrinciple of operation: Pressure gradientCartridge type: Pre polarized condenserFrequency response: 20 Hz to 20 kHzSensitivity nominal ±3 dB at 1 kHz: 6 mV per Pa -44 dB re 1 V per PaEquivalent noise level A weighted: Typically 26 dB A re 20 uPa maximum 28 dB AEquivalent noise level ITU R BS468-4: Typically 38 dB maximum 40 dBDistortion THD less than 1 percent: 134 dB SPL RMS 137 dB SPL peakDynamic range: Typically 111 dBMax SPL THD 10 percent: 144 dB SPL peakRated output impedance: From MicroDot 30 to 40 ohms From DAD6001 BC 100 ohmsCable drive capability: Up to 300 meters with DAD6001 BC XLR AdapterOutput balance principle: Signal balanced with DAD6001 BC XLR AdapterCommon mode rejection ratio CMRR: Greater than 60 dB from 50 Hz to 15 kHz with DAD6001 BC XLR AdapterPower supply for full performance: For wireless systems minimum 5 V maximum 10 V through DPA adapterWith DAD6001 BC: P48 Phantom Power will work from 12 VCurrent consumption: Typically 1.5 mA microphone 3.5 mA with DAD6001 BC XLR AdapterConnector: MicroDotWeight: Single Ear 10 gMicrophone diameter: 5.4 mmMicrophone length: 10 cmCable length: 1.25 mCable diameter: 1.6 mmPolarity: Positively increasing sound pressure produces positive going voltage at MicroDot pin and pin 2 on DAD6001 BC XLR adapterTemperature range: Minus 40 degrees Celsius to 45 degrees CelsiusRelative humidity RH: Up to 90 percentColor: Black
