Gefen EXT-VGA-141SRN
The Gefen Wireless VGA Extender SR allows a VGA display or projector to be conveniently located up to 30 feet away from the source.
The Wireless VGA Extender SR features signal transmission through walls at resolutions of up to 1280x1024, using industry-proven 2.4GHz 802.11b/g/n Wireless network technology. The Extender can be operated on any one of 4 channels to minimize interference.
This product is a plug-and-play solution. No special configuration is necessary. The Wireless VGA Extender SR system consists of a Sender and a Receiver. The Sender is connected to the VGA source with a VGA cable. The Receiver is connected to the display with a VGA cable. 12V external power supplies are connected to the Sender and the Receiver.
  • Wireless extension of VGA up to 30 feet
  • Maximum Input Resolutions: 1080p@60Hz (Y/Pb/Pr), 1280x1024@60Hz (VGA), 480i@60Hz, 576i@50Hz (SVideo, Composite)
  • Maximum Output Resolutions: 720p@60Hz (Y/Pb/Pr), 1280x1024@60Hz (VGA), 480i@60Hz, 576i@50Hz (SVideo, Composite)
  • Can switch amongst up to four audio/video sources at the display
  • Plug-and-Play installation with no special configuration required
  • 4 wireless channels for resistance to interference
  • L/R Analog Audio supported
  • Specifications
  • Wireless Standard: IEEE 802.11b/g/n
  • Antenna Type: Internal Dipole antenna 2dBi
  • PCM Encoding: 48KHz 16-bit sampling
  • Power Supply: 2 x 12V @ 1A each
  • Audio Inputs/Outputs: 3.5mm mini-stereo jacks
  • Video Inputs:
  • Composite & S-Video : NTSC / PAL / SECAM
  • Y/Pb/Pr : 480i/p , 576i/p, 720p@50/60Hz, 1080i/p@50/60Hz
  • VGA : 640x480@60Hz, 800X600@60Hz, 1024X768@60Hz, 1280X768@60Hz, 1280X1024@60Hz
  • Video Outputs:
  • Y/Pb/Pr: 480p@60Hz, 576p@50Hz, 720p@60Hz
  • VGA: 640x480@60Hz, 800X600@60Hz, 1024X768@60Hz,1280X768@60Hz,1280X1024@60Hz
  • Switchable 802.11b/g/n Channels: 3, 6, 9, 11
  • Operating Temperature: 0-40 C ambient temperature
  • Operating Humidity: 90% maximum (non-condensing)
  • Dimensions: 7.1''W x 4.2''H x 1.0''D
  • Reviews
    Free shipping in Canada. Conditions
    Additional information
    For more information about the EXT-VGA-141SRN, please visit the website of Gefen
