MPN #IQ INDUCTOR EQUALIZER

$4375.00

Financing available
Free shipping in Canada. Conditions

Dual mon parametric EQ, 4 bands: Sub, Bass, Mid, High



Precise & All stepped control. Not your grandpa's EQ
IGS IQ Equalizer is a modern application of the noble sound of analog equalizers. This very precise, parametric equalizer works great on every stage of production. It can add marvelous color to the signal, while maintaining the whole character of the original sound. This is a unique phenomenon possible only with analog processing. As opposed to digital eq it maintains neutrality and clarity on every setting. The simultaneous boosting and cutting of similar frequencies are the core secret of this device.

This is the typical effect of analog filters in the audio path. Most of the sound correction is in micro-manipulation. The frequency range is divided into 4 bands: Sub, Bass, Mid, High. In every band the frequency and boost/cut level can be set.


Finally an inductor EQ with the full, precise control engineers have been waiting for

The frequency range is divided into 4 bands: Sub, Bass, Mid, High, allowing you to control the frequency, boost/cut, bandwidth and bypass of each band! Now imagine two channels of that!!
BASIC FEATURES
Boost/Cut Range : +/- 10 dB
Hard wire bypass : Yes
Q factor : 0.3 - 6

INPUT & OUTPUT
Input Impedance (balanced) : 10k ohm
Output Impedance (balanced) : 600 ohm

LEVELS
Operating Level : +4dBu
Max input level : +22dBu
Max output level : +26dBu

BANDWIDTH
Frequency response : 20 Hz - 20k Hz (+/-0.1 dB)

DISTORTION (@ 20 HZ - 20 KHZ)
Crosstalk : 100 dB

POWER
Voltage : 115/230V, 60/50Hz
Power consumption : 25W
Power supply : internal

PACKING BOX
Dimensions : 70x40x30 cm
Shipping weight : 4 kg
