JDK Audio R20

The JDK Audio R20 is a dual channel, high quality microphone preamp, designed from the ground up by API's design team to offer a versatile high quality input for microphones.

Each channel features both a mic and an instrument input, with switched phantom power, phase, and pad. Metering is traditional analog VU.

The MP-R20 provides 2 channels of premium analog microphone pre-amplification designed to provide a low noise, solid front end for all audio applications. Meticulously detailed and solidly constructed, the R20 features custom analog VU meters and hands-on analog control of the gain level. Individual toggle switches control the selection of 48v, polarity, pad and a mic/instrument switch.

JDK Audio is an entirely new brand developed and engineered by API (Automated Processes, Inc.). And, while API's audio products are benchmarks of the recording world, we decided to embark on a product line that would allow us offer some new ideas and new tools to the audio community.

JDK Audio products feature robust design standards in solid, reliable package. The audio quality, the integrity of the components and the build construction all combine to provide years of great sounding analog audio performance - at a surprisingly affordable price.
Features
  • Dual Mic Preamplifiers with 54 dB of gain
  • Custom analog VU meters for monitoring output level
  • Front panel, high-impedance instrument input with 45 dB of gain
  • Peak indicator
  • Pad switch attenuates the microphone signal by 20 dB, or the instrument signal by 10 dB
  • Switchable 48v Phantom power
  • Low distortion, low noise circuitry
  • Fully balanced output, both 1/4" and XLR
  • Specifications
    Inputs: Balanced XLR Mic jack (rear), Un-Balanced 1/4" Instrument jack (front)
    Outputs: Balanced XLR and 1/4" parallel jacks

    Microphone Input
    Max Gain: +55db (no pad), +36db (w/pad)
    Min Gain: +9db (no pad), -10db (w/pad)
    Pot Gain Range: 46db
    Pad: -20db
    Input Impedance: 6.8K Ohms
    Bandwidth: +/- 0.5db, 20Hz - 50kHz
    THD+N @ 1kHz, +4dbu: 0.013%
    Maximum Level: +20dbu
    Signal-to-Noise Ratio: -90db

    Instrument Input
    Max Gain: +31db (no pad), +21db (w/pad)
    Min Gain: +10db (no pad), 0db (w/pad)
    Pot Gain Range: 21db
    Pad: -10db
    Input Impedance: 500K Ohms
    Bandwidth: +/- 0.5db, 20Hz - 20kHz
    THD+N @ 1kHz, +4dbu: 0.002%
    Maximum Level: +20dbu
    Signal-to-Noise Ratio: -80db

    Current: 65mA, 7.3VoltAmps
    Dimensions: 2U EIA 19" Rack
    Height: 3.5 Inches
    Width: 19 Inches
    Depth: 10 inches
    Weight: 12 lbs
    Reviews
    Price *
    $1589.00
    $1349.00
    Free shipping in Canada. Conditions
    Rental

    Price/Day
    Total
    1 Day
    $27.00
    $27.00
    3 Days
    $18.00
    $54.00
    5 Days
    $13.50
    $67.50
    12 Days
    $9.00
    $108.00
    28 Days
    $5.75
    $161.00
    Additional information
    For more information about the R20, please visit the website of JDK Audio
