The Neumann BCM 705 has a dynamic capsule. With hypercardioid pattern, optimized for the broadcast, featuring integrated pop protection and suppression of structure-borne noise.
Emotion conveyed with technical perfection. This is the ideal which the Neumann microphones in the Broadcast Line have been designed to fulfill. The fine-tuning to the requirements of professional broadcast studios and the individual, functionally optimized design* ensure that these are microphones of character.
The BCM 705 is Neumann's first dynamic microphone. The housing and headgrille are identical to those of the BCM 104; only the green logo indicates that this is something new from Neumann. The principle of reduction to the essentials can be seen in the dynamic capsule with a hypercardioid directional characteristic, specifically designed for speech reproduction at close range. Multi-level isolation from structure-borne noise ensures operation free of interference, even in a lively studio environment.
The microphone headgrille twists off easily for quick cleaning. Neumann offers optional, color-coded headgrilles so that, for reasons of hygiene, each announcer can use his or her individual headgrille. Iin front of the capsule, mounted on a frame holder, a fine gauze serves as a built-in popscreen.
The microphones of the Broadcast Line have an elastic mount against structure-borne noise, that is compatible with standard broadcast-segment microphone arms.
The frequency response has a light treble boost, in the region from 2 kHz to 9 kHz, aiding the speech intelligibility. The bass frequency response is designed to compensate for the overemphasis of the bass caused by the proximity effect.
The integrated Pop Screen
A pop screen not only prevents the occurrence of plosive pop noises in vocal recordings, but also efficiently prevents unwanted particles, from respiratory moisture, nicotine, to food remnants, from settling on the diaphragm. The pop screen can be removed for cleaning without the use of tools.
The preferred mode of operation is to suspend the BCM 104 or BCM 705 from a standard studio boom arm.
A thread adapter to fit different connector threads is included. In order to provide protection from structure-borne noise, both the capsule and the microphone in its mount are elastically suspended.
The optional SG 5 swivel mount allows additional angling of the microphone by +/-90 degrees.
* The design of the microphone is a registered design of the Georg Neumann GmbH in certain countries.
Dynamic capsuleHypercardioid directional characteristicCharacteristic, functionally optimized design*Integrated pop protectionIntegrated suspensionIndividual headgrilles for different usersColored rings to identify the replacement headgrillesEasy removal and cleaning of microphone headgrille (with bayonet mount)Mechanical compatibility with standard studio boom armsMulti-level isolation from structure-borne noiseNo power supply required
Acoustical operating principle : Pressure gradient transducerDirectional pattern : HypercardioidFrequency range : 20 Hz ... 20 kHzSensitivity at 1 kHz into 10 kohm : 1,7 mV/Pa = 55,4 dB ± 1 dBRated impedance : 200 ohmsRated load impedance : >= 10,000 ohmsEquivalent SPL CCIR 468-3 : 32 dBEquivalent SPL DIN/IEC 651 : 18 dB-AS/N ratio CCIR 468-3 : 62 dBS/N ratio DIN/IEC 651 : 76 dBWeight : 500 gDiameter : 64 mmLength : 85 mmHeight (without suspension) : 110 mm
GTIN (UPC/EAN) : 615104085077
Manufacturer Part Number : 008507
