Neumann KH 870 II AES67
MPN #700285
$8375.00
Économisez 15%, Prix suggéré $9849.00
Flagship AoIP DSP subwoofer, dual 10" drivers, 113dB SPL, 16Hz bass, 7.1.4 AES67 I/O, ST 2110 support, MA 1 room correction, for immersive large-room setups.
The Neumann KH 870 II AES67 is the most powerful subwoofer in Neumann's monitoring lineup, designed for large-scale multichannel and immersive audio systems that demand both extreme headroom and networked flexibility. Featuring dual 10" long-throw drivers and an advanced 8-channel bass management system, it extends monitoring accuracy down to 18 Hz with exceptional precision, making it ideal for film scoring stages, broadcast facilities, and immersive production studios.
With AES67 audio-over-IP integration, the KH 870 II AES67 connects seamlessly into modern networked infrastructures, providing reliable, standards-based AoIP compatibility. The subwoofer's high-capacity amplifiers deliver clean, distortion-free output even at the highest levels, while its bass management intelligently routes and balances low-frequency information across complex multichannel setups. Built-in room adaptation controls and full compatibility with Neumann's MA 1 Automatic Monitor Alignment ensure the system performs flawlessly in any acoustic space.
Combining reference-class low-frequency performance with next-generation AoIP connectivity, the KH 870 II AES67 is the ultimate solution for professionals who need uncompromising bass accuracy and robust network integration in their monitoring systems.
Caractéristiques
Dual 10" reference subwoofer with deep, powerful bass extension down to 18 HzAES67 network audio interface for seamless integration into IP-based and broadcast environmentsFully compatible with SMPTE ST 2110, Ravenna, and other AES67 standardsBuilt-in 7.1 Channel Bass Manager with flexible routing and dedicated LFE bypassOptimized for large-scale immersive monitoring, including Dolby Atmos, DTS:X, and other multi-channel formatsSwitchable low-pass filters and adjustable crossover for precise alignment with KH-series monitorsHigh headroom design ensures accurate, distortion-free low-frequency performance at high SPLAcoustically engineered cabinet for tight, controlled bass in professional studiosDual connectivity with balanced XLR and AES67 network portsDesigned as the flagship low-frequency extension for KH 150, KH 310, and KH 420 in multi-channel and immersive systems
Spécifications
General Specifications
Model: KH 870 II AES67Type: Flagship DSP-controlled subwoofer with multichannel bass management and AoIP interfaceFrequency Response (±6 dB): 16 Hz " 750 HzMaximum SPL @ 1 m: 118 dBDriver: 2 - 10"DSP: Integrated, supports MA 1 Automatic Monitor Alignment (sold separately)Bass Management: Multichannel, up to 7.1.4
Analog I/O
Inputs: 2 - XLR, 2 - SUB-D25Outputs: 2 - XLR, 2 - SUB-D25
Digital I/O
AES3 (BNC): Input, Monitor Out, Daisy-chain In/OutAES67 AoIP: 12 input channels processed by the subwoofer, routed to up to 11 connected monitorsNetwork Ports: Redundant AES67 ports compliant with ST 2110, ST 2022-7 redundancy, RAVENNA, and Dante-generated AES67 streams
Performance & Features
Bass extension down to 16 HzTwice the output power of KH 810 IIMultichannel bass management (7.1.4)Optimized for large studios and immersive environmentsSuitable for large KH monitors such as KH 420DSP control for clarity and consistencyRoom correction via MA 1 software (sold separately)
Physical Specifications
Dimensions (H - W - D): 645 - 330 - 645 mmEnclosure: Robust, acoustically optimizedFinish: Anthracite
Power & Protection
Universal power supplyIntegrated limiters and protection circuitry
Delivery Includes
1 - KH 870 II AES67 Subwoofer (anthracite)4 - Mains cables (EU/KR, UK, US, CN)1 - Safety guide1 - "Getting Started Quickly" supplement
