Presonus StudioLive SE 32
UPC/EAN #673454013126
MPN #STUDIOLIVE-SE32
StudioLive Series III SE 32 digital mixer, 40 channels, 26 buses, 33 motorized faders, 64x64 USB, AVB/Milan networking, SD recorder, Bluetooth input, Studio One Pro included
The StudioLive Series III SE 32 Digital Console Mixer is a flagship 40-channel, 26-bus mixing console built for professional touring, broadcast, and install applications. With 33 touch-sensitive motorized faders, a 64x64 USB audio interface, and Milan-certified AVB networking, it delivers unmatched control, versatility, and pristine audio quality in a full-sized one-to-one channel layout. Seamlessly integrated with Studio One Pro and Capture software, it offers one-click Virtual Soundcheck, onboard SD multitrack recording, and real-time streaming capabilities-all directly from the console.
The dual-core FLEX DSP Engine powers studio-grade signal processing, including 8 vintage-modeled compressors and 7 EQs from the Fat Channel Collection, alongside four dedicated effects buses and extensive reverb parameters. Featuring 33 XMAX-Remote preamps, 16 FlexMixes, and built-in Bluetooth audio input, the SE 32 is optimized for modern workflows. Control every detail from anywhere using Metro remote access, Universal Control, or QMix-UC, giving both engineers and performers intuitive command over their mixes. For high-performance environments that demand total integration and control, the StudioLive SE 32 stands at the top of its class.
Features
Full 32-Channel Motorized Mixer: 40-channel, 26-bus mixer with 33 touch-sensitive motorized faders in a full one-to-one layout for hands-on control.Integrated Multitrack Recording & Streaming: Capture every input via 64x64 USB interface or onboard SD recorder; includes one-click Virtual Soundcheck with Capture.Premium Sound Quality: Features 33 XMAX-Remote preamps, 32-bit floating-point DSP, and 115 dB A/D"D/A converters for pristine studio-grade audio on stage.AVB Networking with Milan Certification: Seamlessly integrates with StudioLive Stage Boxes and Milan-compatible gear for advanced networked audio.Advanced Fat Channel Processing: Includes all 7 EQs and 8 compressors modeled after classic hardware, plus dynamic visual control and flexible reverb options.Built-In Bluetooth Input: Wirelessly stream break music or reference tracks directly to the console.Remote Mixing from Anywhere: Use Metro for remote access, Universal Control for local devices, and QMix-UC for personal monitor mixing.Powerful Routing Options: 16 FlexMixes, 4 subgroups, 4 effects buses, and 24 DCAs support custom mix configurations.User-Friendly Workflow Design: High-contrast display, ergonomic layout, and redesigned fader caps provide intuitive control during long sessions.Professional Software Included: Comes with Studio One Pro DAW and Capture software for a complete recording and mixing ecosystem.
Specifications
General Specifications
Product Name: StudioLive Series III SE 32 Digital Console MixerSeries: StudioLiveSKU: 2779200310Color: BlackWeight: 37.2 lbsDimensions: 32.37 in W x 22.97 in D x 6.51 in HPower Consumption: 85 WVoltage Requirements: 100 to 230 VAC 50 to 60 HzOperating Temperature: 0 to 40 Celsius
Mixing and Processing
Total Channels: 40Total Buses: 26FlexMixes: 16 configurable as auxes subgroups or matrixDCAs: 24Subgroups: 4Motorized Faders: 33 touch sensitiveDSP Engine: 32 bit floating point dual core FLEXAD and DA Converters: 115 dB dynamic rangeTotal System Latency: 1.9 msInternal Bit Depth: 32 bitDigital Audio Bit Depth: 24 bitReference Level for 0 dBFS: plus 18 dBuCrosstalk Adjacent Channels: minus 87 dB
Audio I/O
XMAX Remote Preamps: 33Microphone Input: XLR female balancedMic Input Impedance: 1 kOhmMic Gain Range: 0 to 60 dBMic Max Input Level: plus 12 dBuMic SNR: 94 dBMic THD: less than 0.005 percentLine Input: 1/4 in TRS female balancedLine Input Impedance: 10 kOhmLine Input Max Level: plus 18 dBuLine Input SNR: 94 dBLine Input THD: less than 0.005 percentLine Output: 1/4 in TRS female balancedLine Output Max Level: plus 18 dBuLine Output Impedance: 100 ohmsXLR Output Max Level: plus 24 dBuXLR Output Impedance: 100 ohmsTape I/O: RCA stereo unbalancedTape In Max Level: plus 12 dBuTape Out Max Level: plus 18 dBuTape Output Impedance: 100 ohmsHeadphone Output: 1/4 in TRS stereoHeadphone Max Output: 100 mW per channel at 60 ohmsHeadphone Frequency Response: 20 Hz to 20 kHzHeadphone SNR: 96 dBHeadphone THD: 0.01 percent
Digital Connectivity
USB Interface: USB 2.0 Type BUSB Audio Channels: 64 x 64AVB Network Ports: Neutrik etherCONNNetwork Control Port: RJ45Bluetooth Input: Version 4.1 StereoAES EBU Output: XLR male
Recording and Storage
Onboard SD Recorder: WAV formatSD Bit Depth: Record 24 bit Playback 16 or 24 bitSD Sample Rates: 44.1 and 48 kHzMedia Format: FAT16 SD and FAT32 SDHCSD Storage: SD card 2 GB SDHC card up to 32 GB
Software Integration
Included Software: Studio One Pro CaptureVirtual Soundcheck: One click with CaptureDAW Compatibility: Studio One Pro and major DAWsRemote Control: Metro suite Universal Control appPersonal Monitor Mixing: QMix UC
Audio Processing Features
Fat Channel: 8 compressors and 7 EQ modelsModeled Processors: Brit Comp FC 670 Tube EQReverb: XL presets with advanced parametersCustomization: Scribble strip displays dynamic interface
Control and Interface
Display: High contrast ergonomic flat screenFader Caps: Redesigned for comfort and visibilityControl Access: Routing levels processing from any location via Metro or mobile devices
