Radial Engineering Bassbone OD

UPC/EAN #676101041169 MPN #R800 7072

$549.99

Save 16.7%, MSRP $660.00

Financing available

Be the first to write a review

Free shipping in Canada. Conditions

Bass preamp, 2 ch w/overdrive, FX loop, built-in DI & headphone amp

Dual full-featured bass channels
The Bassbone OD allows you to connect two bass guitars and sculpt the tone of each one individually, as each input has its own level and EQ controls. The EQ settings have been specifically tailored for use with basses, and include a high pass filter to roll off excessive low end, along with a selectable center frequency for the Mid EQ boost/cut. Input A features a PZB booster designed for use with upright basses that employ a piezo transducer, while Input B includes a Drag Control impedance correction circuit that adjusts the load presented to magnetic pickups for a more natural tone. Following the input and EQ section, the Bassbone OD allows both instruments to share your effects pedals with an EFX Loop, which then feeds a powerful on-board overdrive.

Features

Toggle between any two basses with ease

Individual EQ controls for each input

Headphone output for silent practice

PZB booster and piezo input for upright bass

Built-in Radial DI with balanced output for the PA

Specifications

Audio circuit type: Discrete class-A FET input with low noise ICs.
Frequency response: 20Hz ~ 18kHz
Dynamic range: 85dB
Gain: Unity gain device
Clip Level: +10dBu at XLR
Total harmonic distortion: 0.05% @ -15dBu
Intermodulation Distortion: 0.2% @ -20dBu
Input Impedance: CH-A: 220K/10M CH-B Variable from 22K to 1.8M
Output Impedance: 300 Ohms at XLR
Equivalent Input Noise: -92dBu at XLR
Noise: -100dB
Maximum Input: +7 dBu
Features
180° polarity reverse, Ground lift, HPF, Drag Control, Level Control, Phase Adjustment, Effects Loop, EQ Control, Boost
Input Connectors: 1/4"
Output Connectors: 1/4", XLR, 3.5mm
General
Construction: 14-gauge steel
Size (L x W x D): 8" x 4.2" x 2" (203 x107 x 48mm)
Weight: 2.55lb (1157 grams)
Shipping size (L x W x D): 10.75" x 5"x 2.75" (273 x 127 x 70mm)
hipping weight: 2.8lb (1270 grams)
Power: +15VDC/400mA adapter included
Conditions: For use in dry locations only between 5°C and 40°C
Warranty: Radial 3-year, transferable
