Sonnet Fusion R400

4-drive, rackmount SATA storage system with removable storage, integrated hardware RAID controller, and USB 3.0 interface. Hardware-based RAID 5, RAID 0, RAID 10 and more.

Performance and Data Security
Data Security IconAre you looking for an affordable multi-drive rackmount storage system Sonnet's Fusion R400 RAID USB 3.0 should be on your short list. At just 1.75" tall, this versatile 4-drive RAID 5 SATA storage system is simple to deploy in most server racks, and delivers reliable operation and simple configuration in a convenient, budget-friendly package. This Sonnet storage system is equipped with a high-performance internal storage controller that manages the enclosed 3.5" hard drives, and offers five drive configuration options (including RAID 5). Its USB 3.0 interface ensures that you will be able to connect the system to just about any computer.

Hardware-Based RAID 5 Storage Controller Onboard
The Fusion R400 RAID USB 3.0's integrated storage controller supports RAID 5 formatting without additional hardware or software, providing data protection in the event of a single drive failure and eliminating the need for a specialized RAID controller card. In addition to RAID 5, the R400 USB 3.0 supports RAID 0, RAID 10, Span, and JBOD drive formatting. With RAID 0, all four drives are combined into a single volume to offer improved performance and full drive capacity, but without any protection in case one of the drives fails. With RAID 10, two drives are combined into a single volume, while the remaining two drives mirror the data on the first two, providing good performance and better file security. Span formatting combines all four drives' capacity into a single, large volume. The JBOD (Just a Bunch Of Disks) formatting option enables more concurrent audio file editing capabilities. Whichever mode you choose, setup is as simple as setting a switch. Drive operation and health status is available at a glance with multi-color LEDs.
  • Protected Data-When drives configured as a RAID 5 set, data transfers up to 240 MB/sec while protecting the data
  • RAID Controller Onboard-Integrated hardware RAID controller supports RAID 5, RAID 0, RAID 10, JBOD, and span drive configurations with no specialized controller card needed
  • Simple Cofiguration-A simple switch enables you to select RAID modes and configure the drives to meet your performance and data security needs
  • Simple Status Display-Multi-color LEDs allow you to determine operating status at a glance
  • USB 3.0 Interface-Single cable to host connection simplifies set up and reduces cable clutter
  • Temperature-Controlled Fan-Operates slowly most of the time, and speeds up with extended, intense disk activity
  • Wide Host Controller Card Compatibility-Compatible with Sonnet's full line of Tempo PCIe and ExpressCard/34 host controllers
  • Cross Platform Compatibility-Supports Mac and Windows, and Linux computers
  • Specifications
    FUS-R4BR5-0TB : Fusion R400 RAID USB 3.0 (0TB)
    Form Factor : Rackmount Storage Enclosure
    External Connectors : One USB 3.0
    Data Transfer Speed : Up to 240 MB/s read, 230 MB/s write, depending on drive configuration(1)
    Drives Supported : Up-to-date compatible hard drives listed on our Certified Hard Drive Compatibility Chart
    Supported Drive Configurations : Hardware-based RAID 0, 5, and 10; span, and JBOD
    Power Supply : Universal 220W, 100-240V AC, 50-60Hz
    Operating Temperature : +32º F to +104º F (0º C to +40º C)
    Dimensions (WxDxH) : 17.0 x 16.25 x 1.75 in. (43.2 x 41.3 x 4.4 cm)
    Weight (with drives, approxmiate) : 14.95 lbs (6.78 kg)
    RoHS Compliant : Yes

    Hardware Compatibility
    Mac® (Intel-based), Windows®, or Linux® computer with USB 3.0 or USB 2.0(1) ports

    OS Compatibility
    OS X® and Server 10.6.8+
    Windows 10, 8, 7, Vista®, Server: 2012, 2008
    Price *
    Free shipping in Canada. Conditions
    Additional information
    For more information about the Fusion R400, please visit the website of Sonnet
