Sony URX-P40/14
MPN #URXP40/14
Portable wireless receiver for UWP-D series systems (UC14: 470 to 542 MHz)
The demand for high quality audio is increasing as high resolution content becomes prevalent in the video production industry. Today?s content creators are faced with the challenge of capturing high-quality audio quickly, reliably and with limited resources.
Offering superb sound quality with digital processing, reliable RF transmission, true double tuner diversity reception and friendly features, the UWP-D series is an ideal partner for ENG (electronic news gathering) and EFP (electronic field production), as well as documentaries and weddings.
Digital audio processing for high quality sound
Advanced digital audio processing technology by Sony assures high quality sound with improved transient response performance. A new [optional] digital audio interface enables direct digital sound recording with many Sony professional camcorders and Alpha interchangeable lens cameras via the SMAD-P5 Multi Interface MI shoe adaptor, bypassing A/D and D/A conversion stages to further ensure excellent sound quality.
Seamless camcorder integration
Integration with compatible Sony camcorders (requires SMAD-P5 Multi Interface shoe adaptor) displays audio information such as RF level meter, audio mute status and transmitter low battery alert in the camera?s viewfinder. Via the SMAD-P5, audio signals are transmitted from receiver to camera without requiring a cable connection. The wireless receiver can also receive power from the camera, with synchronised power on/off between camera and receiver for more effective power management.
Fast, easy frequency setting
Sony?s uniquely user-friendly NFC SYNC feature allows quick, intuitive secure channel setting between transmitter and receiver.
Light, compact design
Reduced system size and weight enable superior mobility in a wide range of applications including news, documentaries, weddings and remote production. The receiver?s compact size and light weight make it an ideal partner for use small camcorders and interchangeable lens digital cameras.
Features
High quality sound with Sony digital audio processingNFC SYNC function for quick and easy secure channel settingTrue double tuner diversity for stable signal receptionChannel memory for fast switching between two receiver frequenciesHeadphone output for monitoringMonitor mode for using a receiver as an ear monitorCompatibility with Sony WL-800/UWP seriesOutput level control for receiverHigh visibility OLED display, ideal for indoor/outdoor useUSB connector for power supplyDigital audio interface support with SMAD-P5 Multi Interface (MI) Shoe Adaptor (option)
Specifications
Oscillator Type : Crystal-controlled PLL synthesizer
Reception Type : True diversity method
Antenna Type : 1/4 ? wavelength wire antenna (angle-adjustable)
Carrier Frequencies : 14UC : 470.125 MHz to 541.875 MHz(UHF-TV channels 14 to 25)
Frequency Response : 23 Hz to 18 kHz (Typical) (UC, U, CE, LA, CN, E, KR models)
Signal-to-Noise Ratio : 60dB (1kHz sine wave, 5kHz modulation)
Distortion (T.H.D) : 0.9% or less (1kHz sine wave, 5kHz modulation)
Audio Delay :
Approx. 0.35 ms (analog output)Approx. 0.24 ms (digital output)Audio Output Connector : 3.5mm diameter 3-pole locking mini jack, external connection
Audio Output Level :
-60 dBV (3.5mm diameter 3-pole locking mini jack, analog output, 0dB audio output level)-20 dBFS (external connection, digital output, 0dB audio output level)-50 dBFS (external connection, analog output, 0dB audio output level)Analog Audio Output Adjustment Range : -12dB - +12dB (3dB step)
Headphone Output Connector : 3.5mm diameter mini jack
Headphone Output Level : Max. 10mW (16-ohm)
Tone Signal Frequency :
In UWP-D compander mode: 32.382 kHzIn UWP compander mode: 32 kHzIn WL800 compander mode: 32.768 kHzDisplay : OLED
Power Requirements :
DC 3.0 V (two LR6/AA size alkaline batteries)DC 5.0 V (supplied from USB Type-C connector)Battery Life* :
Approx. six hours*Battery life has been measured with two Sony LR6/AA size alkaline batteries at 25 °C (77 °F) DISPLAY MODE set to AUTO OFF.Operating Temperature : 0 °C to 50 °C (32 °F to 122 °F)
Storage/Transport Temperature : -20 °C to +55 °C (-4 °F to +131 °F)
Dimensions : 63 - 70 - 31 mm (2 1/2 - 2 7/8 - 1 1/4 in.) (W / H / D) (excluding antenna)
Mass : Approx. 131 g (4.6 oz) (excluding batteries)
