Tascam ML-4DOUT-X
UPC/EAN #043774033850
MPN #ML-4DOUT-X
$1269.00
Save 19.9%, MSRP $1585.00
4 balanced XLR outputs, 4 Dante I/O, PoE support, DSP with matrix mixer, 10-band EQ, scene presets, remote control software, compact half-rack design.
The TASCAM ML-4D/OUT-X is a robust 4-channel Dante output interface designed for professional audio installations, broadcast environments, and contractor applications. Featuring balanced XLR line outputs and support for 24-bit/96kHz audio, it seamlessly converts Dante audio streams into pristine analog signals. With a built-in DSP matrix mixer and advanced output processing tools-including EQ, filters, delay, and limiting-the ML-4D/OUT-X delivers flexibility for customized zone control and system optimization.
Equipped with PoE support, daisy-chain Dante capability, and compact half-rack size, the ML-4D/OUT-X integrates easily into new or existing networked audio systems. Users can configure and control the unit via TASCAM's intuitive DCP CONNECT or EZ CONNECT software, available for both desktop and mobile platforms. Whether used as a standalone output device or part of a larger Dante network, the ML-4D/OUT-X provides high-performance signal routing and rock-solid reliability.
Features
4 Dante Inputs and 4 Balanced Line Outputs (XLR): Converts Dante signals to analog XLR outputs, ideal for integration with pro audio systems.Built-In DSP Matrix Mixer: Mix and route audio with a 4-in/4-out matrix, featuring EQ, filters, delay, limiter, ducking, and ambient noise compensation.Flexible Output Routing: Send Dante input directly to line out, through DSP processing, or back to the Dante network.PoE Powered: Operates with Power over Ethernet - no separate power adapter required.Compact Half-Rack Design: Easily mounts under desks or installs in a rack with optional shelf (AK-RS1).Remote Control and Monitoring: Supports full or simplified control via TASCAM DCP CONNECT and EZ CONNECT software on desktop and mobile devices.Clear Visual Feedback: Signal and Dante connection indicators monitor audio levels and network status in real time.Scene Memory and Routing Flexibility: Store and recall up to 50 system presets; supports daisy-chaining without a network switch.
Specifications
General Specifications
4 channel line output Dante converter with built-in DSP mixer4 balanced line outputs on XLR connectors4 Dante input and output channelsSupports PoE Power over Ethernet class 024 bit resolution with sampling rates of 44.1 48 88.2 96 kHzHalf rack mountable sizeBuilt-in 4 in 4 out matrix mixer with ducking and ambient noise compensation10 band EQ high pass filter low pass filter delay and limiterConfigurable output reference levels from plus 15 dBu to plus 24 dBuSignal indicators for output monitoringLAN and Dante connection status indicatorsRemote control via DanteTwo software control options: DCP CONNECT for full control and EZ CONNECT for simplified useCompatible with Windows macOS iOS and AndroidSupports Dante daisy chainingIncludes surface mount brackets for under desk or wall installationOptional rack shelf AK-RS1 for mounting two units in a 19 inch rack
Audio Performance
Frequency response 20 Hz to 20 kHz at 44.1 48 kHz and 20 Hz to 40 kHz at 88.2 96 kHzDistortion THD plus N 0.002 percent max at minus 1 dBFSSignal to noise ratio 108 dBCrosstalk 100 dBDynamic range 108 dB
Analog Outputs
Connector type: XLR-3-32 balancedOutput impedance: 200 ohms or lowerNominal output: plus 4 dBuMax output levels: plus 15 dBu at minus 9 dBFS, plus 18 dBu at minus 14 dBFS, plus 20 dBu at minus 16 dBFS, plus 22 dBu at minus 18 dBFS, plus 24 dBu at minus 20 dBFS
Dante Interface
Connectors: 2 x RJ45 for Dante and dataProtocol: DanteEthernet standard: 1000BASE-T IEEE 802.3abCable requirement: Cat 5e or higher STP cables
Power and Environmental
Power supply: PoE class 0 or optional TASCAM PS-P1220E AC adapterPower consumption: 4WOperating temperature: 0 to 40 degrees CelsiusDimensions: 214 x 44.45 x 136.1 mmWeight: 863 grams
Included Items
ML-4D OUT X unitInstallation brackets x 2Owner's manual with warranty
