Tascam MP-800U
MPN #MP-800U
MP800U SD USB player with FM tuner, USB DAC, optional Bluetooth, XLR RCA out, pitch control, fade in/out, remote, 1U rackmount, app and Ethernet control
The MP-800U is a sleek, 1U rackmount media player that blends professional-grade playback versatility with modern convenience. Whether you're outfitting a hospitality venue, corporate AV setup, or retail space, this all-in-one player provides reliable performance through multiple playback sources including SD cards, USB flash drives, Bluetooth audio, FM radio, and USB DAC functionality.
Designed with both integrators and end-users in mind, the MP-800U features balanced XLR and unbalanced RCA outputs, a dedicated tuner output, and flexible level adjustments. Advanced playback functions like Auto Cue, Pitch Control, Power-on-Play, and Key Original ensure smooth transitions and professional control. With optional integration into Q-SYS environments and remote operation via Bluetooth or Ethernet, it fits seamlessly into modern AV systems.
Features
Multi-Source Playback: Plays audio from SD cards, USB drives, FM radio, and Bluetooth (with optional adapter).USB DAC Functionality: Streams high-quality audio from computers and mobile devices via USB-C.Built-In FM Tuner: Offers direct radio playback with dedicated tuner output and 20 preset stations.Balanced & Unbalanced Outputs: Includes XLR and RCA outputs with adjustable levels for flexible system integration.Pro Playback Tools: Features Auto Cue, Auto Ready, Pitch Control, Key Original, Fade In/Out, and Power-on-Play.Remote & App Control: Control playback with included remote or optional Bluetooth app (TASCAM MCC).External Integration Options: Optional Ethernet card enables Q-SYS platform compatibility and Telnet control.Track Access & Safety: Direct track selection via number keys and panel lock to prevent mishandling.Compact Rackmount Design: 1U size fits seamlessly into professional AV racks and installations.
Specifications
General Specifications
SD USB player with FM tuner Bluetooth receiver and USB DAC1U rackmount sizePower supply AC 100 to 240V 50 or 60HzPower consumption 14WDimensions 482.8 x 46.5 x 297.1 mmWeight 2.7 kgOperating temperature 0 to 40 degrees Celsius
Supported Media and Formats
SD card SDHC SDXC 512MB to 512GBUSB flash drives 512MB to 512GBFile systems FAT16 FAT32 exFATSupported formats WAV 44.1kHz and 48kHz 16 or 24bit LPCMMP3 44.1kHz and 48kHz 32 to 320kbps VBRAAC 44.1kHz and 48kHz 32 to 320kbps VBR MPEG4 AAC LCMax file size 4GBMax files 999Max folder depth 16Max file path length 260 characters
Audio Performance
Frequency response 20Hz to 20kHz plus 0.5 dB minus 1.0 dBDistortion 0.005 percent or lessSignal to noise ratio 95 dB or higherDynamic range 95 dB or higherChannel separation 95 dB or higher
Analog Outputs
Balanced XLR output +4 dBu 1.23 VrmsMax XLR output +20 dBu 7.75 VrmsXLR output impedance 100 ohmsUnbalanced RCA output -10 dBV 0.316 VrmsMax RCA output +6 dBV 2.0 VrmsRCA output impedance 210 ohms
Tuner Output
RCA output -10 dBV 0.316 VrmsMax tuner output +6 dBV 2.0 VrmsOutput impedance 210 ohms
Headphone Output
Connector 6.3mm stereo jackMax output 20 mW plus 20 mW at 32 ohms
Control and Connectivity
USB DAC via front USB Type-C portBluetooth audio with optional AK-BT2 adapterControl via free TASCAM MEDIA CONTROL CENTER appEthernet control with optional IF-E100 expansion cardRemote start with optional RC-20CONTROL I/O 3.5mm and 2.5mm TRS for fader start stop and tallyUSB audio streaming USB 2.0 high speed 480 Mbps USB audio 2.0 class compliantRemote port 2.5mm TRSCONTROL IN 3.5mm TRS active low triggerCONTROL OUT 3.5mm TRS open collector
Tuner Specifications
Frequency range FM 87.5 to 108.0 MHzAntenna connector F-type jack
Playback Features
Auto cue and auto readyPower on playIncremental playKey original playback speed without pitch changeFade-in fade-outRepeat including A-B repeat all and singleDirect track access via number keysPanel lock disables front buttonsOutput level adjustment per output
Included Items
MP-800U main unitPower cordWireless remote control RC-MP800AAA batteries x2FM antennaRack mounting kit with screws and washersSecurity screwTASCAM ID registration guideSafety guide including warranty
