IGS AUDIO

Vanad 500

500 Series Preamps

500-series mic/line/Hi-Z preamp, stepped controls, 60dB gain, Carnhill transformers, HPF, phase reverse, +48V phantom, LED meter, 8Hz–20kHz, ideal for tracking

$1,265.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The IGS Audio Vanad 500 is a versatile, character-rich mic/instrument preamp built in the API 500-series format, ideal for engineers seeking vintage tone with modern control. Equipped with Carnhill input and output transformers, the Vanad 500 delivers a warm, harmonically rich sound that enhances everything from delicate vocals to aggressive guitar lines. Designed for maximum flexibility, it features both rear XLR and front-panel Hi-Z inputs, making it an excellent tool for tracking microphones, instruments, or line-level sources with equal precision.

At the heart of the Vanad 500 are fully stepped controls input gain, output level, and a 3-position high-pass filter (OFF/30Hz/100Hz) which allows for accurate, recallable settings ideal for both studio and live use. You can shape tone and manage gain staging easily using the input pad (-30dB to 0dB in 3dB steps) and separate output trim, making it possible to drive the transformers for added color while keeping levels in check. It also features +48V phantom power, phase reverse, and a clear LED bar meter for real-time visual feedback.

With up to 60dB of gain, 18dB of headroom, and a wide frequency response from 8Hz to 20kHz, the Vanad 500 maintains low noise (-99 dBA) and low distortion (THD+N up to 0.2%) while preserving sonic detail. Whether you're tracking vocals, reamping guitars, or adding analog richness to line-level sources, the Vanad 500 brings precision, punch, and musical warmth to any signal chain all in a compact, road-ready 500-series format.

Features

Versatile Mic and Instrument Preamp
Designed for API 500-series racks, the Vanad 500 handles mic, line, and Hi-Z sources with clarity and character.

All-Stepped Controls
Gain, output, pad, and filters use stepped switches for precise, repeatable settings in professional workflows.

Transformer-Balanced Tone
Carnhill transformers on input and output deliver rich, analog warmth and depth.

Hi-Z Front Input
Front-panel jack allows easy connection of guitars, keyboards, or reamping signals without additional gear.

Dual Gain Control
Separate input and output knobs let you drive the preamp for color while keeping output levels in check.

Built-In Filters and Tools
Includes a high-pass filter (30Hz/100Hz), phase reverse, and +48V phantom power for flexible recording setups.

LED Metering
Bright LED bar shows signal level and helps dial in clean or colored tones with ease.

Ideal for Any Source
Works great with dynamic, condenser, and ribbon mics, as well as line-level instruments and reamp setups.

Specifications

General Specifications
Device Type: Microphone/Instrument Preamplifier
Format: 500-Series Mono Module
Transformer Type: Carnhill Input and Output Transformers
Input Types: Mic (XLR Rear), Hi-Z (Front)
Controls: Stepped Switches for Input Gain, Output Level, PAD, HPF
Indicators: LED Bar Graph for Gain Reduction
Additional Functions: Phase Reverse, +48V Phantom Power, High-Pass Filter

Performance
Frequency Response: 8 Hz – 20 kHz ±0.1 dB
Maximum Gain: 60 dB
PAD Range: –30 dB to 0 dB (3 dB Steps)
Max Input Level (Line): +20 dBu
Max Output Level: +22 dBu
Noise Level: –99 dBA
THD+N (@ 0 dBu): Up to 0.2%
Operating Level: +4 dBu

Input/Output
Input Impedance (Balanced): 1.2 kΩ
Output Impedance (Balanced): 600 Ω
Output Connector: XLR (via Rack)

Filters
High-Pass Filter: OFF / 30 Hz / 100 Hz (6 dB/Octave)

Power
Power Source: Requires API 500-Series Compatible Rack
Power Consumption: 3 W
Current Draw: 110 mA per slot

Physical
Dimensions (H x W x D): 13.3 cm x 3.8 cm x 15.8 cm
Shipping Weight: 0.9 kg
Compatibility: API 500-Series Racks Only
