ADAM  |  SKU: 14357

T5V

Active Monitors

The T5V is a highly affordable two-way nearfield monitor and optimized for small control rooms

$279.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

With its 5" woofer the bass-frequency response of the T5V extends to 45 Hz. The new U-ART tweeter, a breakthrough solution for use in high-resolution recording and mixing on a budget, goes up to 25 kHz and is mated to a precision waveguide with the same dispersion-control attributes as the High Frequency Propagation (HPS) waveguide used in ADAM Audio's flagship S Series monitors. The waveguide's highly uniform dispersion of high frequencies provides an incredibly wide sweet spot that frees you from being glued to a rigid mix position while working.

A beveled cabinet with a rear-firing bass reflex port and a small footprint allows placement anywhere in your room, no matter how small, and contains built-in DSP-controlled driver crossovers and equalization as well as multi-way analog connections. Powered with a 50 W Class D amplifier for the woofer and a 20 W Class D amplifier for the U-ART tweeter, the T5V produces SPLs of up to 106 dB per pair.

Excellent acoustic characteristics, small dimensions and an outstanding cost/performance ratio make this studio monitor perfectly suited for use in small control rooms in music, video and broadcast production.

If you need to hear more bottom end, the T5V is compatible with the ADAM Sub7 and Sub8 subwoofers.

Features

U-ART 1.9" Accelerated Ribbon Tweeter


Allows longer operation with fewer signs of fatigue
Their breakup is prevented by the folded diaphragms, distortions are effectively reduced to a minimum
Advanced dynamic range due to acoustically effective diaphragm surface that is 2.5 times bigger (compared to a classic tweeter according to the piston principle)

The air velocity ratio of 4:1 during the sound generation by folded U-ART membrane


Direct, fast response in the high-range even with complex transients

HPS waveguide from the S Series


Makes dispersion more consistent and imaging more stable over a wider area
Reduction of early reflections on the surfaces of, e.g. mixing consoles, desks, etc.

Lightweight polypropylene construction of the woofer


Excellent transient response even at high sound levels without breakup of the diaphragm

Vertical 2-way system with 5" woofer


High resolution of the stereo image

Spacious rear-firing bass reflex port


Bass reproduction with very low compression

Linear frequency response of 45 Hz to 25 kHz


Unbiased reproduction in a wide frequency band

Maximum peak sound pressure per pair in 1 m 106 dB


Powerful, compression-free sound reproduction even at very high sound levels

DSP-powered crossover design


Smooth frequency response without interferences between the drivers in the critical mid-range

Simple room acoustic adjustments via high- and low-shelf filters


Allows optimal adaptation to acoustically difficult listening environments or individual preferences

Analog inputs over XLR and RCA


Optimized for balanced and unbalanced line signals

Acoustically optimized cabinet geometry


Reduction of unwanted reflections on the cabinets

Compact cabinet dimensions


Fits every desktop

2 years warranty with optional extension to 3 years with the registration of the product


Full repair service if required for 5 years

Specifications

WOOFER

Number: 1

Basket Ø: 5" (127 mm)

Cone Material: Polypropylene

TWEETER

Number: 1

Type: U-ART

Diaphragm Area: 4 inch² (2420 mm²)

Equiv. Diaphragm Ø: 1.9" (48 mm)

Velocity Transform Ratio: 4:1

Diaphragm Weight: 0.17 g

Waveguide: HPS

BUILT-IN AMPLIFIERS

Number: 2

Woofer: 1

Type: PWM

Amp. Power RMS: 50 W

Tweeter: 1

Type: PWM

Amp. Power RMS: 20 W

CONTROL OPTIONS

Input Sensitivity: Switchable +4 dBu / -10 dBV

Gain: Yes

High-Shelf: - 2 dB, 0 dB, +2 dB

Low-Shelf: - 2 dB, 0 dB, +2 dB

INPUT CONNECTORS

Analog: XLR, RCA

Input Impedance: 10 kOhm / 20 kOhm

GENERAL DATA

Panel: Rear

Frequency Response: 45 Hz - 25 kHz

THD > 80 Hz: 0.5 %

Max. SPL per pair at 1 m: 106 dB

Crossover Frequency: 3 kHz

Max. Power Consumption: 132 W

Weight: 12.6 lbs (5.7 kg)

Height x Width x Depth: 11.7" x 7" x 11.7" (298 mm x 179 mm x 297mm)

Delivery Contents: Power cord, Quick Start Guide
