TRIAD-CCT-U

Two battery cup inputs, one TA4M input, USB-C output, passive combining, no telemetry, supports AC priority and hot-swaps, compact durable cable for audio gear


Shipping calculated at checkout.

Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The AudioRoot TRIAD-CCT-U is a passive power-combining cable engineered for professionals who need a compact, flexible, and smart-free solution for managing multiple DC power sources. Featuring three DC inputs and a dual USB-C + USB-A output, this configuration is ideal for setups that include both traditional Li-ion battery packs and modern USB-C AC power adapters. Its passive, non-telemetry design ensures compatibility with the Audioroot vmDBOX series and other non-SMBus power distributors, delivering uninterrupted power without the complexity of data merging or battery monitoring.

With its built-in support for USB-C output, the TRIAD-CCT-U is particularly suited for modern power configurations, including USB-C-powered distribution hubs or accessories. When the third input uses USB-C, pairing it with a PPS-compatible USB-C PD adapter is strongly recommended to ensure accurate voltage regulation and to protect battery integrity. The 60 cm cable length provides optimal balance between flexibility and manageability in tight setups such as sound bags or field rigs. Whether you're extending runtime, hot-swapping batteries, or integrating AC backup, the TRIAD-CCT-U delivers clean, reliable power, wherever your gear takes you.

Features

Three Power Inputs Combined
Merges up to three DC sources to extend runtime or enable AC backup.

No Telemetry Support
Passive design works with non-smart batteries and basic power systems.

Dual USB-C + USB-A Output
Delivers power through both USB-C and USB-A ports for flexible device support.

Includes TA4M as Input
Features TA4M connector for one of the three power inputs.

Supports Hot-Swapping
Allows seamless switching between power sources without downtime.

Customizable Build
Made to order with configurable cable lengths and connector types.

Reliable 5A Output Capacity
Handles demanding gear with consistent power delivery.

Specifications

General Specifications
Device Type: Passive Power-Combining Cable
Design: Passive, Non-Telemetry (No SMBus Communication)
Use Case: Redundant Power Supply, Hot-Swap, Extended Runtime
Compatibility: Audioroot vmDBOX Series and Non-Telemetry Third-Party Power Distributors
Input Connectors: 2 × Battery Cup, 1 × TA4M
Output Connector: USB-C + USB-A
Cable Length: 60 cm (Default)
Construction: Durable Cabling and Connectors
Build Type: Built to Order

Electrical Specifications
Maximum Recommended Output Current: 5.0 A

Input Requirements
Battery Cup Inputs: Accept Standard 16.8V Li-ion Batteries
TA4M Input: Requires ≥ 16.8V DC Power Supply (e.g., Audioroot DUO-PSU)

Output Specifications
Output Connector Type: USB-C + USB-A
Output Voltage: Follows Input Voltage (Passive Pass-Through)
