BRAINSTORM ELECTRONICS

DXD-8

Master Clocks

Universal Clock, precision reference generator with 8 universal outputs, generates up to 4 independant references simultaneously, includes WC, AES, Video Sync & 10MHz - Options: PTP, OCXO, GPS

$4,599.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The DXD series from Brainstorm is designed to ease the transition to IP. The DXD-8 Universal Clock, a precision multiformat reference generator generates up to 4 independent video syncs and audio clocks simultaneously. With the PTP option, it acts as a bridge between an IP infrastructure and legacy A/V equipment.

Features

Flexibility and easy integration

4 separate Reference Generators

8 universal outputs (WC, AES, VID SYNC, 10MHz)

2 external reference inputs with failover for redundancy

Synchronizes to a legacy reference, a PTP network or a GPS clock

Remote control via web browser

Multiple options: PTP, GPS, OCXO

Specifications

Reference Generator:

Generates simultaneously up to 4 different rates in any of these formats:

Word clock - rates from 32 to 384 KHz

AES - rates from 32 to 96 KHz

Video sync:

NTSC/PAL black burst

525/29.97/30i

625/23.98/24/25i

HD tri-level sync

720/23.98/24/25/29.97/30/50/59.94/60P

1080/25/29.97/30i

1080/23.98/24/25/29.97/30sF

1080/23.98/24/25/29.97/30/50/59.94/60p

10MHz

Universal Outputs:

8 outputs - in 4 pairs

BNC - 75

Output signal: any of the generated legacy references

Oscillators:

TCXO: +/- 1ppm

OCXO: +/-10ppb (option)

External Sync Sources:

Word clock

AES

Video sync (Black Burst or HD tri-level sync)

10MHz

GPS (Option)

Universal Inputs:

2 BNC input connectors w/ 75 termination switch

Accepts the following input signals:

Word clock

AES

Video sync (Black Burst or HD tri-level sync)

10 MHz

Remote control:

Web browser

Battery backup:

An on-board battery keeps the internal time-of-day clock running while power is off

Presets:

10 presets can be programmed for quick recall

Display:

2.4" TFT LCD - 240 x 320 resolution

Power:

12 VDC @ 5A - External, switching power supply

Dual inputs with auto switch-over for redundancy

Dimensions:

19" x 1.75" x 8"

PTP (option):

Complies with IEEE-1588 V2

Unicast / Multicast operation

Configurable as a Grandmaster, slave or Boundary clock

1 Gigabit Ethernet port (RJ-45)

GNSS/GPS (option):

The DXD-8 can be fitted with an Internal GPS receiver.

The option includes an SMA antenna input connector. An antenna is required (not included).
