1 3
FRANKLIN AUDIO

RA-20

D.I.

Re-amplifier, passive stereo, balanced XLR/TRS inputs, dual TS outputs, variable impedance 600Ω–50kΩ, ground lift, polarity switch, 12dB attenuation

$430.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

The Franklin Audio RA-20 Stereo Studio Re-Amplifier is a compact, fully passive device designed to connect your digital recordings with the character and depth of guitar amps and pedals. It converts balanced, line-level signals from your audio interface into instrument-level outputs, allowing you to send tracks from your DAW back through amplifiers or effects with ease. Its transformer-balanced design requires no external power, keeping your setup simple and reliable in both studio and home environments.

With two independent channels and four selectable routing modes, the RA-20 offers a wide range of creative possibilities. You can run dual mono re-amp chains, split a mono source to two different destinations, or maintain a true stereo signal path through stereo pedals. Each channel includes passive level trim and variable impedance controls, giving you hands-on control over how your signal interacts with amps and high-impedance gear. Ground lift and polarity switches help reduce hum and resolve phase issues, supporting clean and focused recordings.

From re-amping a dry DI guitar to processing drum loops, synths, or even full mixes through pedal chains, the RA-20 makes it easy to explore new textures using the equipment you already own. Its desktop-friendly format and intuitive layout encourage experimentation while keeping your workflow efficient and straightforward.

Features

Stereo Re-Amplification
Send recorded audio from your interface back through guitar amps, pedals, or other instrument gear in full stereo.

Four Routing Modes
Switch between dual mono, mono-to-dual, true stereo, and mono-to-stereo setups to match your workflow.

Balanced Inputs
Connect directly from your audio interface or mixer for clean, studio-ready signal transfer.

Instrument-Level Outputs
Safely feed amps and pedals with the correct signal level for natural tone and response.

Passive Operation
No power supply required, ensuring simple setup and reliable performance.

Transformer Balanced Design
Maintains signal clarity while reducing unwanted noise.

Independent Channel Controls
Adjust level and impedance separately on each channel for precise tone shaping.

Variable Impedance Control
Fine-tune how your signal interacts with amps and pedals to achieve brighter or darker tones.

Ground Lift Switches
Reduce hum caused by ground loops for cleaner recordings.

Polarity Inversion Switches
Flip phase instantly to correct thin or hollow sound issues.

Studio Workflow Friendly
Designed for easy integration into DAW-based setups and modern recording environments.

Durable Build
Built to last with a long-term warranty for peace of mind.

Specifications

General Specifications
Device Type: Passive Stereo Studio Re-Amplifier
Circuit Design: Fully Passive, Transformer-Balanced
Channels: 2 (Stereo)
Configuration Modes: Dual Mono; Mono to Dual Mono; True Stereo; Mono to Stereo
Signal Attenuation: 12 dB
Self Noise: < -96 dBu
THD: < -0.001% at 0 dBu
Power Requirement: None (Passive Operation)
Dimensions: 125 x 65 x 65 mm

Inputs
Input Quantity: 2
Input Connectors: Balanced XLR or TRS Combo
Input Impedance: 10 kΩ

Outputs
Output Quantity: 2
Output Connectors: Unbalanced 6.35 mm (¼") TS
Output Impedance Range: 600 Ω – 50 kΩ (Variable)

Controls & Switching
Level Control: Passive Level Trim per Channel
Impedance Control (Z): Variable Output Impedance per Channel
Ground Lift (GND): Disconnects Pin 1 from Ground
Polarity (Ø): Phase Inversion per Channel
Mode Switching: Dual Button Routing Configuration
