Talent

5.4" 1920 x 1080 AMOLED Touchscreen

For OBSBOT Webcam & PTZ Cameras

2 x HDMI and 2 x USB-A Inputs

NDI/SRT/RTMP Streaming Protocols

Dual-Band WiFi & Bluetooth 5.0 Support

Up to UHD/DCI 4K Video, ISO Recording

Ethernet and USB-C Connectivity

3.5mm Audio Ports, SD Card Slot

Horizontal & Vertical Orientations

Screen

Size: 5.44"

Type: AMOLED

Aspect Ratio: 16:9

Resolution: 1920x1080

Brightness: 350 nits

Color Depth: 8-bit

Contrast Ratio: 6000:1

Color Gamut: 105% NTSC

Refresh Rate: 60Hz

Viewing Angle: All

PPI: 405

Touchscreen: Capacitive

Screen Coating: Anti-fingerprint

Video Input

HDMI: 2x HDMI 2.0 Type-A ports
Resolutions/Frame Rates:

4096x2160p/3840x2160p: 23.98/24/25/29.97/30/59.94/60 fps

1920x1080p: 23.98/24/25/29.97/30/50/59.94/60 fps

1280x720p: 23.98/24/25/29.97/30/50/59.94/60 fps

720x576p, 720x480p, 720x480i: Various frame rates

Color Depth: 8/10/12-bit

Color Sampling: RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2

USB: 2x USB 3.0 Type-A, 1x USB 3.0 Type-C ports
Resolutions/Frame Rates:

Single USB-A or USB-C: Up to 1920x1080p, 60fps

Dual USB-A or USB-A + USB-C: Up to 1920x1080p, various frame rates

Formats: YUYV, MJPG, NV12

Audio Input

3.5mm jack: 1x, 2-channel, 48 KHz, 16-bit

HDMI Port: 2-channel, 48 KHz, 16-bit

USB Port: 2-channel (microphone only)

Bluetooth: 2-channel, 48 KHz, 16-bit

Audio Sources: SRT, RTMP, NDI streams, embedded audio in video files

Background Music: MP3, M4A, WAV files

Video Output

Streaming and Recording:

Codec: H.264, H.265

Resolution: Up to 1080p

Frame Rate: 60/59.94/50/30/29.97/25/24/23.98/15 fps

Bitrate: Up to 62.0Mbps (NDI HX3), down to 256kbps

Key Frame Interval: Customizable

Profile: High profile, Main profile, Baseline profile

Bitrate Mode: VBR, CBR

USB-C: 1x USB 3.0 Type-C port, DP-OUT, UVC/UAC

Resolution: 1920x1080, 60fps

Sampling Format: RGB 4:4:4

Audio Output

Streaming and Recording: 2-channel, 16-bit, 48 KHz, aac, 64kbps/96kbps/128kbps

Headphone Output: 1x 3.5mm jack, 2-channel, 48 KHz, 16-bit

USB-C and USB-A: 2-channel, 48 KHz, 16-bit/24-bit/32-bit

Bluetooth: 2-channel, 48 KHz, 16-bit

Connectivity

Ethernet: 1x RJ45 port, 10/100/1000 Mbps

Wi-Fi: 2.4G/5G, Station and Hotspot modes supported

Bluetooth: BT 5.0

Cellular: USB modem supported (not included)

Storage

Local Storage: 64GB

SD Card: FAT32 (up to 128GB), NTFS, exFAT

Power

AC Power: 12V/1.5A, Max 15W consumption

Battery: 2x DC 7.4V (NP-F battery packs, hot swappable)

Operating Environment

Temperature: -10 to 50C (Operating), -20 to 70C (Storage)

Humidity: 5% to 90% non-condensing

Additional Features

PTZ Control, AI Auto Tracking, Chroma Key, Multi-Cam Recording, Live Streaming (YouTube, Twitch, Facebook), ISO Recording, Telestration, Video Overlays

Size & Weight

Size

147.2mm x 90mm x 28.5mm

Weight

With Stand: 402.9g

Without Stand: 495.2g

What's in the box

OBSBOT Talent Power Adapter x1

Mini Stands x 2

Sun Hood x1

Thumb Screws x 2
