TASCAM

Tascam US-16X08

USB

The TASCAM US-16x08 captures 16 mic and line inputs to your computer with clear sound quality and advanced features to manage big sessions

$719.00 CAD
Shipping calculated at checkout.
Talk to our experts
Our team of experts is here to support you.

Delivery & Shipping

Free Shipping in Canada with orders over $200. Conditions apply. View details here.

Financing

Affirm

Break your purchase into easy monthly payments, quick approval and no hidden fees.
Click here for more info.

Equilease

Ideal for larger purchases, Equilease offers customized leasing solutions to fit your business needs.
Click here for more info.

Returns & Policy

You can review our terms and conditions here

Description

Eight Ultra-HDDA microphone preamps deliver the cleanest and quietest operation in their class while delivering up to 56dB of gain. An additional eight line inputs are provided, two of them switchable to instrument level for direct guitar or bass recording. Eight balanced line outputs are also available, two with a level control on the front panel for monitoring.

Built into the US-16x08 is a DSP Mixer for low-latency digital mixing. Each channel has four-band EQ and compression for polished-sounding monitor mixes. In addition to interface mode, the US-16x08 can be used stand alone as a standalone mic preamp. Mac and Windows drivers are provided, as well as USB Class Compliant 2.0 drivers for tablets like Apple's iPad. MIDI input and output are also available on the rear panel.

Whether using the ergonomically-designed angled desktop stand or mounting with the included rack ears, the US-16x08 includes analog I/O for almost any music recording application.

Features

The TASCAM US-16x08 captures 16 mic and line inputs to your computer with clear sound quality and advanced features to manage big sessions. ltra-HDDA (High Definition Discrete Architecture) mic preamps with 125dBu EIN

Eight Ultra-HDDA mic pres with XLR connectors, eight TRS inputs

Standalone mode for use as an independent mic preamp

Up to 96kHz/24-bit recording

Support for Windows and Macintosh

USB 2.0 computer connection

Connect with iPads and other iOS devices via Class Compliant drivers

+48V phantom power available for all microphone inputs

High-impedance inputs available

56 dB of preamp gain, ideal for dynamic or ribbon microphones

Tough metal casing for durability

Angled design provides excellent usability on a desktop

Eight TRS outputs

Standard TRS headphones output jack with 70mW/ch output power

Separate controls for line and headphones output volumes

MIDI input and output

Low-latency monitoring via on-board DSP mixer

DSP mixer with 4-band EQ and compression on each input channel

Digital Patch bay allows outputs to be assigned freely

Scenes can store DSP mixer settings (up to 10 scenes can be stored and named)

USB class compliant 2.0 support

Confirmed operation with major DAW software (SONAR, ProTools, Cubase, Live, Studio One, Garage Band)

RoHS certified

Dedicated AC adapter included.

Specifications

Sampling frequency 44.1k/48k/88.2k/96kHz

Quantization bit rate 16/24bit

Analog audio inputs

MIC IN (IN 1-8)

Connector XLR-3-31(1:GND, 2:HOT, 3:COLD), BALANCED

Input impedance: 2.4k ohms

Nominal input level:

GAIN: MAX:-68dBu (0.0003Vrms)

GAIN: MIN:-12dBu (0.195Vrms)

Maximum input level: +8dBu (1.947Vrms)

Gain:56dB

INST IN (IN 9-10)

Connector 6.3mm(1/4") TS-jack(T:HOT, S:GND), UNBALANCED

(When set to "INST" at LINE/INST switch)

Input impedance: 1M ohms or more

Nominal input level

GAIN:MAX:-57dBV (0.0014Vrms)

GAIN:MIN:-12dBV (0.251Vrms)

Maximum input level: +8dBV (0.2512Vrms)

Gain:45dB

LINE IN (IN 9-10)

Connector 6.3mm(1/4") TRS-jack(T:HOT, R:COLD, S:GND), BALANCED

(When set to "LINE" at LINE/INST switch)

Input impedance: 10k ohms

Nominal input level:

GAIN:MAX:-41dBu (0.0069Vrms)

GAIN:MIN:+4dBu (1.228Vrms)

Maximum input level: +24dBu (12.182Vrms)

Gain:45dB

LINE IN (IN 11-16)

Connector 6.3mm(1/4") TS-jack(T:HOT, S:GND), UNBALANCED

(When set to "-10dBV" at LEVEL switch)

Input impedance: 10k ohms or more

Nominal input level: -10dBV (0.3162Vrms)

Maximum input level: +10dBV (3.162Vrms)

LINE IN (IN 11-16)

Connector 6.3mm(1/4") TRS-jack(T:HOT, R:COLD, S:GND), BALANCED

(When set to "+4dBu" at LEVEL switch)

Input impedance: 10k ohms

Nominal input level: +4dBu (1.228Vrms)

Maximum input level: +24dBu (12.182Vrms)

Analog audio outputs

LINE OUT (LINE OUT 1-8)

Connector: 6.3mm(1/4") TRS-jack(T:HOT, R:COLD, S:GND), BALANCED

Output impedance:100ohms

Nominal output level:+4dBu (1.228Vrms)

Maximum output level:+24dBu (12.177Vrms)

PHONES

Connector: 6.3mm(1/4") stereo phone jack

Maximum output level: 70mW+70mW or more (THD+N 0.1% or less, 32ohms loaded)

MIDI IN / OUT


Connector: Din 5-pin
Format: Standard MIDI format

USB

Connector: USB B type 4-pin

Format: USB2.0 HIGH SPEED mass storage class

Power: Dedicated AC adapter (GPE248-120200-Z, included)

Power consumption: 12W

Dimensions: 52" W x2.32" H x8.62" D inch , 445mm W x59mm H x219mm D


Weight: 2.8kg / 6.11lb
Operating temperature: 5 to 35C
Accessories: Rack mount adapter, USB cable, User's manual, warranty card, dedicated AC adapter (GPE248-120200-Z)

Audio performance

Frequency response

LINE OUT(BALANCED)

44.1k/48kHz: 20Hz to 20kHz, +/-0.3dB(JEITA)

88.2k/96k Hz: 20Hz to 40kHz, +/-0.3dB(JEITA)

THD: 0.008% or less

S/N ratio: 100dB or more

Crosstalk: 100dB or more

EIN: -125dBu or less

Computer system requirements

Windows

OS: Windows 7 (32-bit SP1, 64-bit SP1), Windows 8.0 (32-bit, 64-bit), Windows 8.1 (32-bit, 64-bit)

Compatible computers (Windows-compatible computer with a USB 2.0 port)

CPU type/speed Dual core/2 GHz or faster

Memory: 2GB or more

DRIVER: ASIO2.0, WDM(MME)

Macintosh

OS OS X Mountain Lion(10.8), OS X Mavericks(10.9)

Compatible computers (Apple Macintosh computer with a USB 2.0 port)

CPU type/speed Dual core/2 GHz or faster

Memory 2GB or more

DRIVER Core Audio, Core MIDI

iOS

OS iOS 7
