Volt 2 Gen2

Tone-Shaping Preamps
Choose from Warmth, Focus, and Shine modes to add tube, solid-state, or British Class-A character while recording.

Dual-Source Recording
Two input channels accommodate vocals, instruments, or stereo sources recorded simultaneously.

Instrument Inputs
Front-panel high-impedance connections provide direct input for electric guitars, basses, and other compatible instruments.

Automatic Level Control
Auto-Gain sets recording levels quickly, while Clip Protection helps prevent unexpected peaks from distorting a take.

Full-Color Display
Clear visual feedback provides quick access to input levels, channel settings, and other recording information.

Independent Phantom Power
Each microphone channel provides individually switchable phantom power for compatible condenser microphones.

Loopback Audio
Computer audio and live sources can be combined for podcasts, livestreams, video calls, and other content.

USB Bus Power
Power from a compatible computer or mobile device supports recording without an external power supply.

Production Software
Included recording software, plug-ins, instruments, effects, and amplifier tools provide a complete starting point for music production.

General Specifications
Device Type: USB audio interface
Simultaneous I/O: 2-in / 4-out
Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz
Bit Depth: 32-bit
USB Standard: USB 2.0
USB Connector Type: USB-C
Loopback: Built-in
Digital I/O: None
MIDI I/O: None

Analog Inputs
Microphone Preamps: 2
Microphone Preamp Gain: 60 dB
Mic / Line Inputs: 2
Instrument Inputs: 2
Phantom Power: +48V, independently switchable per channel
Microphone Connector Type: XLR combo
Line Connector Type: 1/4-inch TRS balanced or TS unbalanced
Instrument Connector Type: 1/4-inch TS unbalanced

Analog Outputs
Monitor Outputs: 1 stereo
Headphone Outputs: 1 stereo
Headphone Cue Mixes: 1
Monitor Connector Type: 1/4-inch TRS balanced
Headphone Connector Type: 1/4-inch TRS stereo

USB Connectivity
USB Host Port: 1
External Power Input: 5V DC, 1A minimum

Power
USB Bus Power: Supported
Typical Power Consumption: 3.4W at 5V DC
Maximum Power Consumption: 4.9W at 5V DC
Power Switch: None

Instrument Input Performance
Frequency Response: 20 Hz to 20 kHz, ±0.02 dB
Dynamic Range: 116 dB, A-weighted
THD + Noise: -108 dB, 0.0004%
Maximum Input Level: 13 dBu
Input Impedance: 1 MΩ
Available Gain: 60 dB

Microphone Input Performance
Frequency Response: 20 Hz to 20 kHz, ±0.08 dB
Dynamic Range: 119 dB, A-weighted
THD + Noise: -110 dB, 0.0003%
Maximum Input Level: 14 dBu
Input Impedance: 2 kΩ
Available Gain: 60 dB

Line Input Performance
Frequency Response: 20 Hz to 20 kHz, ±0.05 dB
Dynamic Range: 119 dB, A-weighted
THD + Noise: -108 dB, 0.0004%
Maximum Input Level: 22 dBu
Input Impedance: 10 kΩ
Available Gain: 60 dB

Monitor Output Performance
Frequency Response: 20 Hz to 20 kHz, ±0.05 dB
Dynamic Range: 126 dB, A-weighted
THD + Noise: -112 dB, 0.0003%
Maximum Output Level: 20.2 dBu
Output Impedance: 200 Ω
DC Coupled: Yes

Headphone Output Performance
Frequency Response: 20 Hz to 20 kHz, ±0.08 dB
Dynamic Range: 116 dB, A-weighted
THD + Noise: -103 dB, 0.0007% into 300 Ω
Maximum Output Power at 32 Ω: 45 mW
Maximum Output Power at 300 Ω: 24 mW
DC Coupled: Yes

System Requirements
Computer Connection: Available USB 2.0 or higher port
Processor: Intel, AMD, or Apple silicon
Windows: Windows 10 64-bit or newer
macOS: macOS 12 Monterey or newer
Mobile Operating System: iPadOS or iOS 16 or newer
DAW Compatibility: Major digital audio workstations
Internet Connection: Required for software downloads
