Driven by a massive built-in 450W amplifier to deliver over 118dB SPL at very low distortion down to well below 20Hz.

The SCM0.1/12 can be used as the ELF in a multi-channel system or will extend extreme LF in 2 channel systems with smaller monitors - ideal for use with SCM20ASL PRO.

A versatile interface provides for easy set up with phase, level, low pass and contour controls. Low pass frequencies are adjustable

ATC 12/314mm bass driver.

Massive motor assembly.

In-house, hand wound precision flat wire coils.

ATC 450W amplifier

Active filters and overload protection

Drivers: 314mm (12")

Cut-off Frequencies (-3dB free standing): 18Hz & 250Hz

Max Continuous SPL: 112dB SPL @ 1 metre

Input Connectors: 2 xMale XLR

Input Sensitivity: 1V Balanced

Input Impedance: >10k Ohms

Common Mode Rejection: >90dB

Harmonic Distortion (amplifier): <0.01%

Amplifier Output

Continuous: 450 Watts

Dynamic: 1000 Watts

Overload Protection: Active FET momentary gain reduction

Gain Control Range: ±6dB

Contour Equaliser: 6dB lift @ 40 - 60Hz

Filter Characteristics: 50Hz, 60Hz, 70Hz, 80Hz, 90Hz low pass second order critically damped

Power Requirements: 100, 115, 230V (factory set for territory), 50/60Hz

Cabinet Dimensions (HxWxD): 581 x 530 x 530mm (22.9 x 20.9 x 20.9)

Overall Weight: 68kg (150lb)
