UPC/EAN #814164021265     MPN #ATOMSHBH01


Free shipping in Canada. Conditions

Shinobi uses our revolutionary AtomOS 10 platform and is packed with an extensive suite of scopes and simple one-touch operations. 5" HDR Photo & Video Monitor.

Shinobi includes monitoring tools for focus, framing & exposure, including Focus Peaking, 4:1 / 2:1 / 1:1 Zoom, Zebra, False Color, Frame Guides, SMPTE Safe Area, Waveform, RGB parade, vectorscope, a new multi-view 'Analysis' view and a flexible 3D and 1D LUT , Profile and Preset support (upload .cube files via SD Card) and options for anamorphic desqueeze monitoring.
Without batteries: 196g / 7oz.
Dimensions (W x H x D mm): 151 x 91.5 x 31.5mm
Construction: Polycarbonate ABS
Mounting points: 1/4"-20 screw mount. 1x top and 1x bottom

Operating power: 4 - 7W
Compatible batteries: NP-F series and supporting accessories. AtomX or other.
Input voltage (battery): 6.2V to 16.8V
Battery time (based on 7.4V):
  • Standby: 2600mAh - 3hrs, 5200mAh - 6hrs, 7800mAh - 12hrs
  • Monitor: 2600mAh - 1.5hrs, 5200mAh - 3hrs, 7800mAh - 6hrs

  • DC In: via Battery Eliminator

    Size: 5.2"
    Resolution: 1920 x 1080
    PPI: 427
    Aspect ratio: 16:9 native
    Color Gamut: REC709 HDTV
    Look up table (LUT) support: 3D LUT (.cube format) *Extended Support planned
    Anamorphic de-squeeze: 2x, 1.5x, 1.33x
    Technology: IPS panel (capacitive touch), calibration to Rec.709 with optional calibration unit

    AtomHDR: Yes

    HDR Monitoring (Gamut)
  • Sony SLog / SLog2 / SLog3, Canon CLog / CLog2 / Clog3,
  • Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 / LogCEI1000 / LogCEI1280 / LogCEI1600
  • Panasonic Vlog
  • JVC JLog1
  • RED Log3G10 /RED LogFilm
  • FujiFilm F-log
  • PQ10k, HLG, Nikon N-Log

  • HDR Monitoring (Gamma)
  • Sony SGamut / SGamut3 / SGamut3.cine
  • Canon Cinema / DCI P3 / DCI P3+
  • Panasonic V Gamut
  • Arri Alexa Wide Gamut
  • Rec709 / BT.2020
  • JVC
  • RED WideGamut / RED DragonColor / DragonColor2 / RED Color2 / RED Color3 / RED Color4

  • Bit Depth: 10-bit (8+2 FRC)
    Brightness: 1000nit (+/- 10%)
    Screen Mirror/Flip: Horizontal Flip (Selfie mode), Vertical Flip
    * Landscape/Portrait mode planned for future firmware release

    Video Input
    HDMI: 1 x HDMI (1.4)
    Signal: Up to Uncompressed true 10-bit or 8-bit 422 (camera dependent)

    Supported Formats (Video Input)
    4K 4096 x 2160: 23.98p, 24p, 25p, 29.97p
    UHD 3840 x 2160: 23.98p, 24p, 25p, 29.97p
    HD 1920 x 1080: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
    HD 1280 x 720: 50p, 59.94p

    Audio In (48kHz)
    HDMI: 2ch 24-bit 48kHz

    Audio Out
    Headphone out: 3.5mm

    SD Card Slot
    Full size SD Card slot: SD Card Slot allows LUTs to be loaded to the unit and is also used when updating AtomOS firmware

    Monitoring Features: Luma Waveform, RGB parade, RGB Overlay, Vectorscope, Vectorscope Zoom, Histogram, RGB Histogram, Anlaysis mode (Multiview scopes: Waveform, Histogram, Vectorscope), Focus Peaking, Zebra, False Color, Blue Only Exposure, Zoom (1:1, 2:1, 4:1), SMPTE Safe Areas, Cinema Guides, Anamorphic Desqueeze.

    What's In The Box
    Included: Shinobi unit, 12V-15W AC power supply, Quick Start guide
    Optional Accessories:
    Power Kit: 2 x NP-F Batteries, 1 x charger, 1 x power supply
    AtomX 5" Sunhood (compatible w. Shinobi / Ninja V)
    AtomX 5" Screen Protector (compatible w. Shinobi / Ninja V)
    AtomX 10" Arm & Quick Release Plate (by Lanparte)

    Atomos HDMI cables
    Xrite i1 Display Pro Calibrator and USB to Serial cable
    AtomX 5" Accessory Kit
    Warranty: 1 year
