APOGEE

SYM2-8X8MP-TB3-DAN

8 mic/line in, 8 line out, Connect8 module, Thunderbolt 3, Pro Tools HD/Dante, AES, optical, SP coax, modular I/O, premium AD/DA, touchscreen control.


$10,890.00 CAD
Frais de livraison calculés lors du paiement.

Parlez à nos experts
Notre équipe d'experts est là pour vous accompagner.

Livraison & Expédition

Livraison gratuite au Canada pour les commandes de plus de 200 $. Des conditions s'appliquent. Voir les détails ici .

Financement

Affirm

Divisez votre achat en paiements mensuels faciles, avec une approbation rapide et sans frais cachés.
Cliquez ici pour plus d'informations.

Equilease

Idéal pour les achats plus importants, Equilease propose des solutions de financement personnalisées adaptées aux besoins de votre entreprise.
Cliquez ici pour plus d'informations.

Retours et politique

Vous pouvez consulter nos conditions générales ici

Description

L'Apogee Symphony I/O Mk II – SYM2-8X8MP-TB3-DAN est une interface audio polyvalente, prête pour le réseau, qui offre la clarté sonore renommée d'Apogee avec une connectivité hybride avancée. Dotée du module Connect 8, cette configuration fournit 8 entrées micro/ligne haute performance et 8 sorties ligne, idéale pour enregistrer voix, instruments et ensembles avec un détail sans compromis. Le système inclut également des E/S numériques AES, optiques et coaxiales S/PDIF, offrant une intégration flexible avec une large gamme d'équipements numériques.

Intégré dans le châssis modulaire SYM2, cette interface est équipée d'une carte Thunderbolt 3 pour des performances ultra-faible latence avec les DAW natifs, ainsi que d'une carte option Pro Tools HD/Dante, en faisant un hub exceptionnel pour les studios hybrides. Que vous enregistriez dans Pro Tools HD, routiez l'audio via un réseau Dante, ou produisiez nativement via Thunderbolt, cette configuration relie tout cela parfaitement. Avec un second emplacement E/S laissé libre pour une expansion future, le SYM2-8X8MP-TB3-DAN offre une solution puissante et évolutive pour les professionnels exigeant un son impeccable et une connectivité totale dans une interface élégante.

Caractéristiques

8 Mic/Line Inputs with Premium Preamps
Equipped with Apogee’s Connect 8 module for ultra-clean mic and line-level recording.

8 Balanced Line Outputs
Ideal for monitoring, analog summing, or routing to outboard gear.

Hybrid Connectivity
Includes Thunderbolt 3 for native DAW workflows plus Pro Tools HD and Dante for studio and networked environments.

Flexible Digital I/O
Supports AES/EBU, Optical, and S/PDIF coaxial formats for digital gear integration.

Touchscreen Interface
Front-panel display offers quick control over levels, metering, and routing.

Modular and Expandable
Second I/O slot is open, allowing easy upgrades or customization.

Perfect for Modern Hybrid Studios
Combines analog quality with digital flexibility for tracking, mixing, or broadcast use.

Made in the USA
Built with Apogee’s legendary quality and attention to professional detail.

Spécifications

General Specifications
Device Type: Modular Multi-Channel Audio Interface
Chassis: Symphony Mk II
SKU: SYM2-8X8MP-TB3-DAN
I/O Configuration: 8 Mic/Line Inputs, 8 Line Outputs
Connectivity: Thunderbolt 3, Pro Tools HD, Dante
Digital I/O: AES/EBU, Optical (ADAT or S/PDIF), S/PDIF Coaxial
Touchscreen: Front-Panel High-Resolution Display
Control Software: Apogee Maestro, Dante Controller
Use Case: Professional Tracking, Hybrid Networked Studios, Dante/Pro Tools Integration

Module Configuration
I/O Module 1: Connect 8
– Analog Inputs: 8 Mic/Line Combo Inputs (XLR/TRS)
– Analog Outputs: 8 Line Outputs
I/O Module 2: Empty (Available for Expansion)

Connect 8 Mic/Line Inputs
Input Type: Combo XLR–¼″ TRS
Gain Control: Digitally Controlled
Phantom Power: +48V, Individually Switchable per Channel
Input Sensitivity: –55 dBu to +24 dBu
EIN: Approx. –118 dBu
Dynamic Range: Up to 122 dB A-weighted
THD+N: Approx. –115 dB @ –1 dBFS
Input Impedance: 10kΩ (Line), 3kΩ (Mic, typical)

Digital-to-Analog Conversion (Line Outputs)
Output Count: 8 Line Outputs
Dynamic Range: Up to 126 dB A-weighted
THD+N: –119 dB @ 21dBu
Maximum Output Level: ∞ to +24 dBu
Output Impedance: 50Ω
Circuitry: Apogee Perfect Symmetry Circuitry (PSC), Balanced

Digital I/O
AES/EBU: Stereo I/O
Optical: ADAT (8-Ch) or S/PDIF
S/PDIF Coaxial: Stereo I/O

Network & Expansion Interfaces
Primary Interface: Thunderbolt 3
Option Card: Pro Tools HD / Dante (Dual-Port Network and HDX/HD Native Integration)

Power Requirements
Input Voltage: 90–240VAC
Frequency: 50–60Hz
Power Consumption: 150W

Mechanical
Chassis: 19-Inch Rack-Mount
Rack Units: 2U
Construction: Steel Housing
Module Slots: 2 (1 Populated, 1 Empty)

Compatibility
Thunderbolt: macOS 10.10 and above
Pro Tools HD/HDX: macOS and Windows
Dante: macOS and Windows
Software Support: Apogee Maestro, Pro Tools, Dante Controller

Model Identifier
SKU: SYM2-8X8MP-TB3-DAN
